Product Short Description
Technical Specifications:
- Channels: Dual-channel configuration for independent temperature measurement.
- Input Types: Compatible with Bently Nevada-approved RTD (Resistance Temperature Detector) sensors (e.g., PT100, PT1000) and thermocouples (Type J, K, T, E).
- Temperature Range:
- RTD Input: -200°C to +850°C (-328°F to +1562°F) (configurable based on sensor type).
- Thermocouple Input: -200°C to +1200°C (-328°F to +2192°F) (type-dependent).
- Accuracy:
- RTD Input: ±0.1°C (±0.18°F) for PT100 sensors.
- Thermocouple Input: ±0.5°C (±0.9°F) for Type K sensors.
- Sampling Rate: Up to 10 samples per second per channel.
- Output Signals:
- Relay Outputs: 4 form-C relays (2 per channel) for alarm and trip functions.
- Analog Outputs: 2 (4–20 mA) for temperature indication.
- Environmental Resistance:
- Operating Temperature: -30°C to +70°C (-22°F to +158°F).
- Storage Temperature: -40°C to +85°C (-40°F to +185°F).
- Humidity: Up to 95% non-condensing.
- Protection: IP66-rated for dust and water resistance.
- Power Consumption: 8 W per module.
- Certifications: Meets API 670 standards and is SIL 2-certified for safety applications.
Description
Functional Features:
- Dual-Channel Monitoring: Independently measures and analyzes temperature from two sensors simultaneously.
- High-Precision Measurement: Sub-0.5°C accuracy ensures reliable detection of temperature changes.
- Programmable Alarms: User-configurable thresholds for high-temperature, low-temperature, and rate-of-change alarms.
- Signal Conditioning: Converts raw sensor data into standardized temperature units (°C or °F).
- Self-Diagnostics: Continuously monitors module health and alerts users to potential issues via LED indicators (OK, Alarm, Trip).
- Seamless Integration: Works with the 1701 FieldMonitor™ system rack and System 1 software for centralized data logging and trending.
- Flexible Configuration: Supports customization of temperature ranges, alarm thresholds, and output signals.
- Cold Junction Compensation: Automatically adjusts thermocouple readings for accurate temperature measurement.
Application Scenarios:
- Turbomachinery: Monitors bearing temperatures in turbines and compressors to prevent overheating and lubrication failure.
- Motors and Generators: Tracks winding and bearing temperatures to detect insulation degradation or cooling system issues.
- Pumps: Detects abnormal temperature rises in pump bearings or seals to avoid mechanical failures.
- Reactors: Monitors process temperatures in chemical reactors for safe and efficient operation.
- Furnaces and Boilers: Ensures optimal combustion temperatures to improve efficiency and prevent damage.
- HVAC Systems: Tracks air handling unit temperatures for energy optimization and comfort control.
- Transformers: Monitors oil and winding temperatures to prevent overheating and insulation breakdown.
- Marine Propulsion: Safeguards ship engines and generators by monitoring critical temperature points.
Key Advantages:
- High Precision: Sub-0.5°C measurement accuracy for reliable temperature monitoring.
- Dual-Channel Design: Enables simultaneous monitoring of two separate temperature points.
- Rugged Construction: Withstands harsh industrial environments, including extreme temperatures and vibrations.
- Scalability: Supports up to 14 modules in a single 1701 FieldMonitor™ system rack.
- Cost Efficiency: Reduces downtime and maintenance costs through early fault detection.
- Safety Compliance: SIL 2-certified for use in critical safety applications.
- Easy Integration: Compatible with Bently Nevada’s System 1 software for advanced data analysis and reporting.
