Bently Nevada 13677-01 Proximity Probe System Transmitter Module

Product Short Description

Technical Specifications

Input Signal: Compatible with Bently Nevada 3300 XL series proximity probes (e.g., 8 mm, 5 mm, or 11 mm probes).
Output Signal: Dual-channel voltage output (typically ±10 VDC) proportional to shaft vibration or position.
Frequency Response: 0 Hz to 10 kHz (adjustable based on application requirements).
Linearity: ±1% of full scale over the operating range.
Supply Voltage: 24 VDC ±10% (compatible with standard industrial power supplies).
Operating Temperature: -20°C to +70°C (-4°F to +158°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Enclosure Rating: IP66 (dust-tight and protected against water jets).
Mounting: DIN rail or panel-mountable for flexible installation.
Weight: Approximately 500 grams (1.1 pounds).

Key Features

High Accuracy: Provides precise measurements of shaft vibration and position, ensuring early detection of mechanical anomalies.
Dual-Channel Design: Enables simultaneous monitoring of two measurement points, reducing installation complexity.
Adjustable Gain: Allows customization of sensitivity to match specific application requirements.
Built-In Filtering: Reduces noise and interference for cleaner signal output.
Diagnostic Capabilities: Monitors probe health and system integrity, alerting users to potential issues.
Easy Integration: Compatible with Bently Nevada’s System 1 platform and third-party monitoring systems via standard interfaces.

Application Scenarios

Power Generation: Turbines, generators, and compressors in thermal, hydro, and nuclear power plants.
Oil & Gas: Rotating equipment such as pumps, motors, and centrifuges in upstream and downstream operations.
Petrochemicals: Reactors, extruders, and fans for process reliability and safety.
Steel Industry: Rolling mills, blast furnaces, and conveyor systems for vibration monitoring.
Manufacturing: High-speed spindles, CNC machines, and assembly line equipment for precision control.

Industry Compliance

Meets API 670 standards for machinery protection systems.
Certified for use in hazardous environments (ATEX, IECEx, and CSA approvals available upon request).

Benefits

Predictive Maintenance: Enables early detection of imbalances, misalignments, and bearing wear to prevent unplanned downtime.
Cost Efficiency: Reduces repair costs by extending equipment lifespan through timely interventions.
Safety Enhancement: Mitigates catastrophic failures by providing real-time alerts for abnormal vibration or position changes.
Centralized Monitoring: Integrates with Bently Nevada’s System 1 platform for comprehensive asset health management.
