Product Short Description
Technical Specifications:
- Type: Power supply and signal conversion module for涡流 sensors (eddy current probes).
- Input Signals:
- Accepts raw signals from 3300 XL series eddy current probes.
- Supports keyphasor sensor inputs for phase and speed measurements.
- Output Signals:
- Standardized analog outputs: 4–20 mA or -2.0V to -18.0V DC.
- Digital keyphasor signal conversion for phase analysis.
- Power Supply: +24 VDC (typical industrial voltage).
- Operating Temperature: 0°C to +65°C (continuous operation).
- Storage Temperature: -40°C to +85°C.
- Relative Humidity: Up to 95% (non-condensing).
- Physical Dimensions: 24.2 cm × 11.2 cm × 2.5 cm.
- Weight: 0.38 kg.
- Installation: Standard DIN rail mounting for control cabinet integration.
- Protection Class: IP20 (indoor use).
Description
Functional Features:
- Signal Conversion: Processes raw sensor data into standardized analog signals for compatibility with DCS, PLC, or monitoring systems.
- Keyphasor Processing: Converts mechanical keyphasor signals into digital outputs for precise speed, phase, and alignment measurements.
- Multi-Configuration Support: Enables paired or triple-module redundant (TMR) setups for enhanced reliability.
- Noise Filtering: Tracking filters eliminate electrical interference, improving measurement accuracy.
- Diagnostic Capabilities: Monitors sensor and system health to detect faults early.
- Communication Protocols: Interfaces with Ethernet/IP, Profinet, Modbus, and RS232/485 for seamless network integration.
Key Applications:
- Power Generation: Turbine and generator vibration monitoring in power plants.
- Oil & Gas: Centrifugal compressor and pump condition monitoring.
- Manufacturing: Predictive maintenance of motors, gearboxes, and production line machinery.
- Chemical Industry: Stability monitoring of reactors and process equipment.
- Marine Engineering: Ship propulsion system and offshore platform monitoring.
- Mechanical Protection: Triggers alarms or shutdowns for generators, pumps, and motors when abnormal vibrations or displacements occur.
Industry Compliance:
- Meets API 670 standards for mechanical protection systems.
- Certified for harsh industrial environments with robust temperature and humidity tolerance.
Integration with Monitoring Systems:
- 3300 XL Series: Works as a core component for axial vibration, displacement, and keyphasor measurements.
- 3500 Series: Functions as a 3500/25 Keyphasor Module or signal conditioner for vibration monitors.
- DCS/PLC Compatibility: Outputs analog signals for integration with distributed control systems (DCS) or programmable logic controllers (PLC).
Enhanced Design Benefits:
- Improved Signal Processing: Enhanced keyphasor signal accuracy compared to legacy systems.
- Redundancy Support: TMR configurations ensure continuous operation during partial system failures.
- Scalability: Adaptable to small-scale equipment or large industrial plants.
