Product Short Description
Technical Specifications
- Channels: Four independent channels, each configurable for different measurement functions.
- Input Types: Accepts signals from displacement sensors and 3500 stator-mounted air gap sensors (SMAGs).
- Measurement Functions:
- Vibration monitoring
- Position monitoring
- Air gap measurement
- Shear pin failure alarm (by combining shaft clearance movement with NX amplitude)
- Signal Processing: Advanced signal processing capabilities to ensure signal stability and accuracy.
- Communication Protocols: Supports various communication protocols for seamless integration with other devices or systems.
- Environmental Rating: Designed to operate in harsh industrial environments with a wide temperature range.
- Approvals: CSA/NRTL/C (Class 1, Division 2), ATEX/IECEx/CSA (Class 1, Zone 2).
Description
Key Features
- High Precision and Reliability: Utilizes high-quality components and materials to ensure accurate and reliable measurements.
- Multi-Channel Monitoring: Supports simultaneous monitoring of multiple measurement points, providing comprehensive coverage of rotating machinery.
- Continuous Comparison: Continuously compares monitored parameters with alarm setpoints to drive alarms and prevent equipment damage.
- Flexible Configuration: Each channel can be independently programmed using the 3500 framework configuration software to meet specific application requirements.
- Easy Integration: Compatible with the Bently 3500 series monitoring system and supports various communication protocols, facilitating easy integration into existing control systems.
- Robust Design: Built to withstand harsh industrial conditions, ensuring long-term stable operation.
- Shear Pin Failure Alarm: By combining shaft clearance movement with NX amplitude, it can provide a shear pin failure alarm, enhancing mechanical protection.
Application Scenarios
- Hydroelectric Power Plants: Monitors the vibration and position of hydro turbines and generators to ensure safe operation and prevent equipment damage.
- Pump Storage Power Stations: Used to monitor the vibration and position of water turbines and pumps to ensure normal operation and prevent failures.
- Other Industrial Applications: Can also be applied to other industrial rotating machinery, such as compressors and pumps, to monitor their vibration and position and ensure safe operation.
