Product Short Description
Technical Specifications
- Channels: Four independent channels, each configurable for different measurement types.
- Input Types:
- Displacement: Electro-hydraulic proximity sensors.
- Velocity: Seismic velocity sensors.
- Acceleration: Seismic acceleration sensors.
- Dual-probe inputs for combined velocity and displacement measurements.
- Sensitivity Ranges:
- Radial Vibration: 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil).
- Axial Displacement: 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil).
- Eccentricity: 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil).
- Differential Expansion: 0.394 mV/µm (10 mV/mil) or 0.787 mV/µm (20 mV/mil).
- Dual Acceleration: 10 mV/(m/s²) (100 mV/g).
- Dual Velocity: 20 mV/(mm/s) pk (500 mV/(in/s) pk) or 5.8 mV/(mm/s) pk (145 mV/(in/s) pk).
Description
- Resolution: Up to 24-bit resolution for precise measurements.
- Filter Options: Programmable bandpass, low-pass, and notch filters to eliminate unwanted frequency components.
- Power Consumption: Normal consumption is 7.7 watts.
- Environmental Rating: NEMA 4/4X weatherproof enclosure for harsh environments.
- Operating Temperature Range: -40°C to +85°C, adapting to various industrial settings.
Key Features
- Multi-Channel Monitoring: Simultaneously monitors multiple parameters, enhancing testing and measurement efficiency.
- Flexible Input Configuration: Each channel can be independently configured for displacement, velocity, or acceleration measurements using 3500 rack configuration software.
- High-Precision Measurement: Provides accurate analog signal measurements with low noise levels, ensuring reliable data acquisition.
- Differential Signal Processing: Extracts casing vibration signals from shaft relative vibration, crucial for absolute shaft measurements in large gas and steam turbines.
- Built-In Calibration: Features automatic calibration to maintain measurement accuracy and reliability during operation. It also supports standard calibration procedures for consistent results.
- High-Speed Data Transmission: Utilizes a PXIe bus interface for rapid data transfer to computers for processing and analysis.
- Relay Output: Configurable to activate alarms, initiate shutdown sequences, or trigger other actions in response to measured vibration levels or temperature deviations.
- User-Friendly Interface: Intuitive interface for easy setup, programming, and monitoring.
Application Scenarios
- Power Generation: Monitors turbines, generators, and pumps in power plants to ensure safe operation and prevent equipment damage.
- Oil and Gas: Protects compressors, blowers, and other rotating equipment in production facilities, ensuring continuous and efficient operation.
- Chemical Processing: Ensures safe operation of machinery in chemical plants, preventing accidents caused by equipment failures.
- Manufacturing: Used for equipment status monitoring and predictive maintenance in large industrial machinery, improving production efficiency and reducing downtime.
- Steel and Metals: Monitors rolling mills, fans, and other critical equipment, ensuring stable production processes.
- Pulp and Paper: Protects rotating machinery in paper production lines, preventing production interruptions due to equipment failures.
