Product Short Description
Technical Specifications
- Channels: Four independent channels, configurable for displacement, velocity, or acceleration measurements.
- Input Types:
- Displacement: Electro-hydraulic proximity sensors.
- Velocity: Seismic velocity sensors.
- Acceleration: Seismic acceleration sensors.
- Sensitivity Ranges:
- Radial Vibration: 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil).
- Axial Displacement: 0.787 mV/µm (20 mV/mil).
- Differential Expansion: 0.394 mV/µm (10 mV/mil) or 0.787 mV/µm (20 mV/mil).
- REBAM®: 40 mV/µm (1000 mV/mil) or 80 mV/µm (2000 mV/mil).
- Dual Acceleration: 10 mV/(m/s²) (100 mV/g).
- Dual Velocity: 20 mV/(mm/s) pk (500 mV/(in/s) pk) or 5.8 mV/(mm/s) pk (145 mV/(in/s) pk).
Description
- Filter Options: User-programmable filters including bandpass, low-pass, and notch filters to eliminate unwanted frequency components.
- Output Signals: Processed signals can be output as digital or analog signals for integration with other control or monitoring systems.
- Power Consumption: Normal consumption is 7.7 watts.
- Environmental Rating: NEMA 4/4X weatherproof enclosure for harsh environments.
- Certifications: Meets API 670 standards for mechanical protection systems; optional ATEX, IECEx, and CSA certifications for hazardous areas.
Key Features
- Flexible Configuration: Each channel can be independently configured for displacement, velocity, or acceleration measurements using 3500 rack configuration software.
- High Precision: Provides high-resolution measurements with a wide dynamic range, ensuring accurate monitoring of mechanical conditions.
- Comprehensive Alarm Logic: Supports comprehensive alarm logic for each channel, enabling timely alerts for abnormal conditions.
- Seismic Monitoring: Supports seismic sensors for low-frequency vibration analysis, crucial for early fault detection in rotating machinery.
- Redundancy Support: Compatible with Triple Modular Redundant (TMR) systems for high-availability applications.
- Ethernet Connectivity: Enables integration with System 1 software for advanced data analysis and predictive maintenance.
- User-Friendly Interface: LED indicators for OK, TX/RX communication, and bypass status for easy monitoring of module status.
Application Scenarios
- Power Generation: Monitors turbines, generators, and pumps in power plants to ensure safe operation and prevent equipment damage.
- Oil and Gas: Protects compressors, blowers, and other rotating equipment in production facilities, ensuring continuous and efficient operation.
- Chemical Processing: Ensures safe operation of machinery in chemical plants, preventing accidents caused by equipment failures.
- Manufacturing: Used for equipment status monitoring and predictive maintenance in large industrial machinery, improving production efficiency and reducing downtime.
- Steel and Metals: Monitors rolling mills, fans, and other critical equipment, ensuring stable production processes.
- Pulp and Paper: Protects rotating machinery in paper production lines, preventing production interruptions due to equipment failures.
