Product Short Description
Technical Specifications:
- Sensor Type: Eddy Current Sensor
- Linear Range: 2 mm (0.08 inches)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0–10 kHz
- Output Signal: Voltage (proportional to gap distance)
- Cable Type: Armored cable (FluidLoc option available for oil/chemical resistance)
- Connector: 3-pin MIL-C-5015 (gold-plated contacts, 75Ω impedance)
- Thread Size: M10×1 (standard mounting)
- Housing Material: 316L stainless steel (IP67 rated)
- Operating Temperature:
- Probe: -51°C to +177°C (short-term peak: 204°C)
- Cable: -51°C to +177°C
- Mechanical Durability:
- Cable Tensile Strength: 330 N (75 lbf)
- Vibration Resistance: Up to 20g peak-to-peak
Description
Functional Characteristics:
- Non-Contact Measurement: Eliminates mechanical wear, ensuring long-term stability.
- High Precision: ±0.05 mm accuracy in gap calibration.
- Robust Design: Stainless steel housing and armored cable protect against harsh environments.
- Wide Temperature Range: Operates reliably in extreme conditions, from cryogenic to high-temperature settings.
- EMI Shielding: Reduces electromagnetic interference for stable signal transmission.
- TipLoc and CableLoc Technology: Patented designs ensure secure probe-tip and cable connections, preventing loosening.
Application Scenarios:
- Rotational Machinery Monitoring:
- Turbines (steam, gas, hydro)
- Compressors (axial, centrifugal)
- Pumps and motors
- Industrial Automation:
- Integrates with Bently 3500 series monitoring systems for real-time data acquisition.
- Supports vibration analysis, speed monitoring, and position feedback.
- Power Generation:
- Monitors rotor vibration and axial displacement in generators.
- Petrochemical and Metallurgical Industries:
- Provides continuous vibration data for process control and equipment health management.
Compatibility:
- Works with Bently 3300 series proximity probes, extension cables, and monitoring modules (e.g., 330180前置器).
- Supports integration with PLC, DCS, and vibration analysis software.
Environmental Requirements:
- Humidity: ≤95% RH (non-condensing).
- Target Surface: Metallic surface with dimensions at least twice the probe diameter; no adjacent metal objects within the range.
- Installation Clearance: Minimum 50 mm gap between probe and surrounding structures.
Maintenance and Calibration:
- Regularly inspect the probe and cable for physical damage or contamination.
- Clean the probe tip with isopropyl alcohol to ensure accurate measurements.
- Calibrate using Bently TK-3E or similar eddy current probe calibrators.
