Product Short Description
Technical Specifications:
- Input Voltage: Typically 220V AC (also supports 8-32V DC variants)
- Output Frequency: 50kHz (60kHz in some variants)
- Communication Protocols: Modbus RTU, IEC 61850, DNP3, and other industrial protocols
- Protection Functions: Overcurrent, overvoltage, undervoltage, frequency, and short-circuit protection
- Display: Integrated screen for real-time parameter visualization and status monitoring
- Programming: Supports configuration of protection parameters and operation logic
- Operating Temperature: -20°C to +60°C
- Storage Temperature: -40°C to +85°C
- Protection Rating: IP20 (dust and water-resistant)
- Dimensions: 120mm × 70mm × 43mm (compact design for panel mounting)
- Weight: Approximately 1.6kg
- Certifications: Complies with industry standards for reliability and safety
Description
Functional Features:
- High Precision: Utilizes advanced digital signal processing for accurate measurement and protection.
- Multifunctional Protection: Combines overcurrent, overvoltage, undervoltage, frequency, and short-circuit protection in a single device.
- Flexible Configuration: Supports programming to adapt to specific power system requirements.
- Real-Time Monitoring: Displays current protection parameters and system status via an integrated screen.
- Reliable Hardware: Built with industrial-grade components for stability in harsh environments.
- Safety and Diagnostics: Includes fault diagnosis and protection functions to ensure safe operation and quick troubleshooting.
- Scalability: Integrates with other monitoring and control systems via multiple communication interfaces.
Application Scenarios:
- Power Systems: Protects generators, transformers, and transmission lines in power plants and substations.
- Industrial Automation: Controls and monitors equipment in manufacturing processes, ensuring stable operation.
- Energy Management: Optimizes power distribution and consumption in smart grids.
- Water Treatment: Automates pumping stations and filtration systems for efficient operation.
- Traffic Control: Manages signal lights and smart transportation networks.
- Building Automation: Supports HVAC, lighting, and security systems in large facilities.
Advantages:
- Universal Compatibility: Suitable for diverse power systems and industrial applications.
- High Reliability: Industrial-grade components ensure long-term stability in demanding environments.
- Enhanced Safety: Multilayer security features prevent unauthorized access and operations.
- Ease of Integration: Supports seamless connectivity with ALSTOM’s MicroNet DCS and third-party systems (e.g., ABB, Siemens).
- Compact Design: Space-saving form factor simplifies installation in control cabinets.
