ALSTOM LE109A-1 Power System Control Module

Product Short Description

Technical Specifications:

Power Supply: 24V DC (18-36V DC range)
Input/Output Channels: 4 digital inputs/outputs (individually configurable)
Digital I/O Current Consumption: 0.3A (idle); 2A (all outputs active)
Output Current: 0.5A (sustained, short-circuit and thermal overload protected)
Sensor Interfaces: 4 configurable interfaces supporting incremental encoders (8MHz max pulse frequency) and SSI transmitters (78kHz-5MHz transmission frequency)
Communication Protocols: Ethernet, serial interfaces, and bus interfaces for integration with automation systems
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Protection Rating: IP20 (dust and water-resistant)
Dimensions: Compact design for panel mounting
Weight: 1.6kg (varies by model)
Programming Standards: Supports IEC 61131-3 (ladder logic, function block diagram, etc.)

Functional Features:

Efficient Control: Advanced algorithms enable fast and accurate monitoring of power system parameters, improving stability and efficiency.
Flexible Configuration: Users can customize input/output channels, control strategies, and sensor interfaces to meet specific application requirements.
Real-Time Monitoring: Continuously collects and analyzes data from power systems, providing live status updates and alerts.
Safety Functions: Includes overload protection, short-circuit protection, and fault detection to ensure safe operation.
Diagnostics: Self-testing and intelligent diagnostic tools simplify troubleshooting and reduce maintenance costs.
Scalability: Seamlessly integrates with other ALSTOM modules and third-party systems for complex automation tasks.
User-Friendly Interface: Intuitive programming tools and graphical displays facilitate easy operation and configuration.

Application Scenarios:

Power Generation: Controls and monitors generators, turbines, and governors in power plants.
Substations: Manages transformers, switchgear, and other critical components in electrical substations.
Power Network Management: Enables remote monitoring and control of entire power distribution networks.
Energy Management: Optimizes power production, distribution, and consumption in smart grids.
Industrial Automation: Controls industrial processes, ensuring equipment operates according to preset logic and parameters.
Water Treatment: Automates pumping stations, filtration systems, and flow control in wastewater plants.

Advantages:

Reliability: Built with industrial-grade components for long-term stability in harsh environments.
Flexibility: Supports multiple protocols and interfaces for diverse automation needs.
Security: Ensures data protection through encryption and secure communication channels.
Ease of Integration: Compatible with ALSTOM’s MicroNet DCS and third-party devices (e.g., ABB, Siemens).
Compact Design: Space-saving form factor for easy installation in control cabinets.
