ABB UFC911B106 3BHE037864R0106

Product Short Description

Technical Specifications

Power Supply Voltage: 380V AC
Rated Power: 11kW
Rated Current: 19.7A or 26A
Output Frequency Range: 0.5Hz – 150Hz or 0.5Hz – 400Hz
Overload Capacity: 150% for 1 minute
Input DC Power: 18VDC – 48VDC (for some specific drive – related functions)
Maximum Continuous Current: 3A (for some specific drive – related functions)
Operating Temperature Range: – 10°C to 40°C
Storage Temperature Range: – 20°C to 60°C
Humidity: 5% – 95% (non – condensing)
Protection Level: IP66
Dimensions: 350 x 210 x 140 mm or 480 x 300 x 200 mm
Weight: 8 kg or 25 kg

Function Features

Multiple Control Modes: Supports V/F control, servo control, PID control, etc. It also has position control mode, speed control mode and torque control mode.
Trajectory Planning: Has S – curve trajectory planning function and T – curve trajectory planning function.
Operation Modes: Including network command mode (RS232 mode, RS485 and CAN bus are optional), pulse/direction mode, +/- 10V analog signal mode, PWM signal mode and independent operation mode.
Parameter Adjustment and Monitoring: Through network communication and MotionStudio host computer software, the drive parameters can be conveniently adjusted, controlled and online monitored.
Redundancy and Protection: Has functions such as temperature protection, over – current, over – voltage, under – voltage protection, I2T current limitation, etc. Some also support control parameter saving and alarm history record saving functions.
Easy Installation: The compact size makes it easy to install, and it can be easily adapted to different industrial environments, such as wall – mounted or DIN – rail – mounted.

Application Scenarios

Power Industry: As the core control unit of ACS5000/6000 in high – voltage inverter systems, it is used to adjust large – scale motor – driven equipment such as water pumps, fans, and compressors.
Industrial Automation: Suitable for various industrial automation applications that require control of external equipment, such as automated production lines and intelligent manufacturing systems.
Manufacturing Industry: Used for controlling motors, pumps, compressors, conveyor belts, machine tools, etc.
Energy Management: Can be used to control power generation equipment, transformers and other energy – related equipment to achieve optimal energy management and control.
Building Automation: Used to control lighting, HVAC, valves and other building automation equipment.
