ABB TPC-1582H 3BHB040969R0001 Industrial Touch Panel Computer

Description

Technical Specifications

Core Hardware & Display

• Display Type: 15-inch XGA LCD / 15.82-inch High-Resolution LCD (1280×1024 pixels)
• Touch Technology: 5-wire resistive touchscreen / Projected Capacitive (PCAP) multi-touch
• Processor: 4th Generation Intel Core i3 (1.7 GHz) / Equivalent high-performance processor
• Memory: 4 GB DDR3L SDRAM (expandable)
• Storage: 64 GB Solid-State Drive (SSD) (expandable)
• Operating System: Windows 10 IoT Enterprise / Compatible industrial OS
• Fanless Design: Passive thermal management for silent, reliable operation

Electrical & Power

• Power Supply: 24 V DC ± 10% (industrial-grade power input)
• Power Consumption: ≤ 45 W (typical full-load operation)
• Isolation: Galvanic isolation between power and control circuits
• Overvoltage Protection: Integrated surge protection for power input

Connectivity & I/O Interfaces

• Ethernet: 1 x Gigabit Ethernet (RJ45) for high-speed network communication
• USB Ports: 2 x USB 3.0, 2 x USB 2.0 for peripheral connectivity
• Video Outputs: 1 x HDMI, 1 x VGA for dual-display support
• Serial Port: 1 x RS-232 for legacy device communication
• Expansion: PCIe / Mini PCIe slots; supports iDoor technology for fieldbus expansion (PROFIBUS, Modbus, etc.)
• Wireless: Optional WiFi / 3G / GPS modules via expansion slots

Mechanical & Physical

• Mounting: Panel mount, VESA 75×75 / 100×100 mount compatibility
• Dimensions: 360 mm × 160 mm × 25 mm / 467 mm × 290 mm × 60 mm (model-dependent)
• Weight: 0.5 kg – 5.5 kg (model-dependent)
• Enclosure: Rugged aluminum alloy chassis
• Front Panel Protection: IP65 rated (dust and water resistant)
• Terminals: Screw terminals for power and control signals
• LED Indicators: Power, status, network, and fault indicators

Environmental Ratings

• Operating Temperature: -10 °C to +55 °C
• Storage Temperature: -20 °C to +65 °C
• Humidity: 5% – 95% RH, non-condensing
• Vibration Resistance: IEC 60068-2-6 (5–150 Hz, 2 g rms)
• Shock Resistance: IEC 60068-2-27 (50 g, 11 ms)
• Altitude: Up to 2000 m (no derating)

Compliance & Certifications

• Standards: IEC 61010-1, IEC 60947-4-1, IEEE 802.3 (Ethernet)
• EMC Compliance: IEC/EN 61000-6-2 (industrial immunity), IEC/EN 61000-6-3 (industrial emissions)
• Certifications: CE, UL, CSA, FCC, RoHS compliant

Key Features

Rugged Industrial Design

• Fanless Operation: Eliminates moving parts, reduces maintenance, and enhances reliability in dusty/humid environments.
• IP65 Front Panel: Protects against dust, water splashes, and industrial contaminants, suitable for wash-down areas.
• Wide Temperature Range: Operates reliably in extreme industrial temperature conditions without performance degradation.
• Shock & Vibration Resistance: Withstands mechanical stress from industrial machinery and transportation.
• Long Service Life: Designed for 24/7 continuous operation with MTBF exceeding 100,000 hours.

Advanced Touch & Display Performance

• High-Resolution Display: Delivers crisp, clear visuals for detailed process monitoring and data visualization.
• Multi-Touch Capability: Supports intuitive gesture controls (pinch, zoom, swipe) for efficient operation.
• Anti-Glare Coating: Reduces reflections in bright industrial environments, ensuring optimal visibility.
• Fast Touch Response: Sub-10 ms response time for precise, real-time operator input.
• Wide Viewing Angle: Maintains display clarity from multiple viewing positions.

Powerful Computing & Integration

• High-Performance Processor: Handles complex HMI applications, data processing, and multi-tasking seamlessly.
• Expandable Memory & Storage: Accommodates growing application requirements and data storage needs.
• System 800xA Native Integration: Direct compatibility with ABB’s flagship DCS platform for unified process control.
• Multi-Protocol Support: Connects to PLCs, SCADA systems, and field devices via Ethernet, Modbus, PROFIBUS, etc.
• Remote Management: Built-in SusiAccess software for centralized monitoring, configuration, and firmware updates.

Extensive Connectivity & Flexibility

• Versatile I/O Portfolio: Abundant USB, Ethernet, serial, and video ports for seamless peripheral integration.
• Expansion Capabilities: iDoor technology enables easy addition of fieldbus, wireless, and I/O modules.
• Dual-Display Support: HDMI/VGA outputs allow connection to secondary monitors for expanded workspace.
• Flexible Mounting: Panel and VESA mounting options adapt to various control room and field installations.
• Hot-Swappable Components: Supports quick replacement of storage and expansion modules without full system shutdown.

Enhanced Software & Diagnostics

• Optimized HMI Software: Pre-configured for ABB System 800xA, with support for custom HMI development.
• Real-Time Data Processing: Low-latency data acquisition and visualization for critical process control.
• Comprehensive Diagnostics: Built-in monitoring of system health, temperature, and communication status.
• Fault Logging: Detailed event logging for troubleshooting and predictive maintenance.
• Firmware Upgradability: Online firmware updates ensure access to latest features and security patches.
