ABB TK850 3BSC950192R1 FOUNDATION Fieldbus HSE Interface Module

Description

Technical Specifications

Core Communication Specifications

• Product Type: FOUNDATION Fieldbus HSE Interface Module (AC 800M Series)
• Order Code: TK850 (3BSC950192R1)
• Communication Protocol: FOUNDATION Fieldbus HSE (High Speed Ethernet)
• Controller Compatibility: ABB AC 800M series controllers
• Redundancy: Full 1+1 redundancy support for communication paths
• Module Quantity per Controller: Up to 12 CI865 modules per AC 800M controller
• Subnet Support: Connects to identical or independent FOUNDATION Fieldbus HSE subnets
• Data Transfer Rate: 100 Mbps full-duplex Ethernet communication
• Isolation: Galvanic isolation between fieldbus and controller side

Electrical & Power Specifications

• Power Supply: 24 VDC nominal (19.2 VDC – 28.8 VDC)
• Power Consumption: Typical 8 W
• Isolation Voltage: 2500 VDC (1 minute) between bus interface and power supply
• Insulation Resistance: ≥ 100 MΩ at 500 VDC

Mechanical & Physical Specifications

• Dimensions (W × H × D): 140 mm × 100 mm × 80 mm
• Net Weight: Approximately 350 g
• Mounting: Standard DIN-rail mounting (35 mm)
• Installation Spacing: Minimum 10 mm for adequate heat dissipation
• Protection Class: IP20 (EN 60529)

Environmental & Compliance Specifications

• Operating Temperature: -10 °C to +50 °C
• Storage Temperature: -40 °C to +70 °C
• Humidity: 20% – 95% RH, non-condensing
• Pollution Degree: 2 (IEC 60664-1)
• EMC Compliance: EN 61000-6-2 (immunity), EN 61000-6-4 (emission)
• Surge Immunity: ±2 kV (line-ground), ±1 kV (line-line)
• Certifications: CE, UL, cULus, ATEX Zone 2, RoHS compliant

Key Features

High-Speed Fieldbus Integration

• FOUNDATION Fieldbus HSE Support: Enables 100 Mbps high-speed communication with FOUNDATION Fieldbus devices, supporting large-scale device integration and fast data transfer.
• Multi-Subnet Connectivity: Each module connects to independent HSE subnets, allowing for flexible network design and isolation of different process areas.
• Scalable Architecture: Supports up to 12 modules per AC 800M controller, facilitating extensive system expansion and distributed I/O architectures.

Redundancy & Reliability

• 1+1 Redundancy: Fully redundant communication paths ensure zero downtime in critical applications. Automatic failover occurs without process interruption.
• Industrial-Grade Isolation: High-level galvanic isolation protects the controller from field-side electrical disturbances and ground loops.
• Robust EMC Performance: Designed to operate reliably in harsh industrial environments with high electromagnetic interference.

Simplified Integration & Management

• Plug-and-Play Installation: DIN-rail mounting and straightforward configuration enable quick deployment into AC 800M systems.
• Comprehensive Diagnostics: Built-in monitoring and diagnostic functions provide real-time status of communication links, device health, and module performance.
• Seamless System Compatibility: Fully integrated with ABB Control Builder M software for easy configuration, programming, and maintenance within the 800xA ecosystem.

Flexible Network Design

• Distributed Control Support: Enables the creation of distributed control systems with remote HSE segments, reducing cabling costs and improving system responsiveness.
• Device Interoperability: Compliant with FOUNDATION Fieldbus standards, ensuring compatibility with a wide range of HSE field devices from various manufacturers.
• Hot-Swap Capability: Supports module replacement during system operation, minimizing maintenance downtime.
