Product Short Description
Technical Specifications
-
Processor: Dual-core ARM Cortex-A9 @ 800 MHz
-
Memory: 512 MB DDR3 + 4 GB eMMC
-
Control Cycle: 1 ms minimum
-
PID Loops: 32 simultaneous, ±0.01 % accuracy
-
Digital I/O: 16 configurable points
-
Analog Inputs: 8 channels, 16-bit resolution
-
Communication: Modbus TCP/IP, Ethernet/IP, OPC UA server
-
Power Supply: 24 VDC ±10 %
-
Operating Temperature: –20 °C to +60 °C
-
Enclosure: IP65 aluminum housing
- Certifications: UL 508, CE, IEC 61131-2, ATEX Zone 2
Description
Functional Features
-
Deterministic Control: <50 µs jitter for critical timing tasks
-
Web Server: Remote diagnostics and configuration via any standard browser
-
Anti-Windup Algorithm: Prevents integral saturation in cascaded PID loops
-
Data Logger: 1 million samples with millisecond timestamps
-
Redundant Operation: Supports dual-controller hot-standby configurations
-
Conformal Coated PCB: Withstands 95 % RH in food-grade environments
Application Scenarios
-
Pharmaceutical: FDA 21 CFR Part 11 compliant batch reactors and sterilizers
-
Water Treatment: Pump-station flow and pressure cascades
-
Energy: Solar-tracker positioning and inverter control
-
Automotive: Robotic welding cell coordination and conveyor synchronization
