Product Short Description
Technical Specifications
- Output Configurations: Single-channel, dual-channel, or multi-channel outputs.
- Voltage Measurement Range: Wide range to accommodate varying voltage levels and signal intensities.
- Accuracy: High-precision measurement (±0.5% typical) for reliable data.
- Frequency Response: Optimized for high-frequency signals (specific range depends on application).
- Operating Temperature: -20°C to +70°C (industrial-grade durability).
- Altitude Rating: Up to 3,000 meters for versatile deployment.
- Certifications: Complies with CE, UL, and RoHS standards.
- Physical Dimensions: Compact design (e.g., 115 mm × 45 mm × 25 mm) for space-constrained installations.
- Weight: Approximately 0.38–0.82 kg (model-dependent).
- Power Supply: 24 V DC input with low power consumption.
- Protection: Overcurrent, overvoltage, and short-circuit safeguards.
Description
Functional Characteristics
- High-Frequency Voltage Measurement: Specialized for monitoring high-frequency signals in power systems and electronic equipment.
- Stable Circuit Design: Ensures long-term reliability with minimal drift.
- Anti-Interference Capability: Built-in filtering and shielding to reduce electromagnetic noise.
- Electrical Isolation: Safe operation with protective measures for personnel and equipment.
- Modular Structure: Supports hot-swapping for easy maintenance and reduced downtime.
- Multi-Output Flexibility: Configurable for diverse industrial requirements.
Application Scenarios
- Power System Monitoring: Real-time tracking of voltage stability in grids and renewable energy systems.
- Electronic Equipment Testing: Precision measurement in laboratories and manufacturing.
- Industrial Automation: Integration into PLCs, sensors, and actuators for process control.
- Energy Management: Optimization of energy use in HVAC, lighting, and machinery.
- Robotics: Control of motion trajectories, speed, and sequence in automated arms.
Industry Applications
- Energy: Grid stabilization, wind/solar power integration.
- Oil & Gas: Pipeline monitoring and refinery process automation.
- Chemicals/Pharmaceuticals: Temperature, pressure, and flow control in reactors.
- Automotive: Assembly line automation and electric vehicle charging.
- Building Automation: Smart control of HVAC, lighting, and elevators.
Advantages
- Precision: High-accuracy measurement ensures data reliability.
- Durability: Withstands harsh temperatures, altitudes, and electrical noise.
- Scalability: Modular design supports system expansion.
- Safety: Complies with international electrical standards.
- Efficiency: Low power consumption reduces operational costs.
Software & Tools
- Configuration: ABB Control Builder M and Power Factory for parameter setup.
- Diagnostics: Modbus Poll (third-party) and ABB System 800xA Diagnostic Viewer for real-time alerts.
Compatibility
- Integrates with ABB’s AC800M, Symphony Plus, and Advant Controller platforms.
- Supports Profibus DP, DeviceNet, CANopen, and Ethernet protocols.
