Product Short Description
Technical specifications
-
Processor: Dual-core PowerPC at 1.8 GHz
-
Memory: 2 GB DDR3 expandable to 4 GB
-
Control capacity: up to 50 000 distributed I/O points
-
Scan time: 1 ms deterministic control cycle
-
Redundancy: hot-standby CPU, CEX-bus, Ethernet and S800 I/O, < 100 ms switch-over
-
Communication: two RJ45 10/100/1000 Mbit Ethernet ports (CN1, CN2), PROFINET IRT, OPC UA, IEC 61850, RS-232C (COM3) and isolated RS-485 (COM4)
Description
-
Power supply: 24 V DC (18–32 V), redundant input, 8 W typical
-
Isolation: 2.5 kV channel to system
-
Protection: IP20 conformal-coated housing
-
Certifications: SIL 2, UL 61800-5-1, DNV GL
Functional features
-
99.9998 % uptime in redundant pairs with predictive diagnostics via ABB Asset Monitor
-
Built-in secure boot and dynamic network segmentation for cybersecurity
-
Supports Model Predictive Control (MPC) and advanced PID blocks
-
Hot-swap CPU and I/O modules without process interruption
-
Programmable with IEC 61131-3 languages using Control Builder M or 800xA Engineering Studio
Application scenarios
-
Power plant DCS: turbine control, boiler balance-of-plant
-
Oil & gas: compressor anti-surge, pipeline leak detection
-
Chemical & pharma: batch reactor temperature/pressure control
-
Water treatment: plant-wide SCADA, pump station automation
-
Mining & metallurgy: conveyor drives, furnace regulation
