Product Short Description
Technical Specifications
- Processor: High-performance CPU with configurable performance levels based on SKU.
- Memory: Supports up to 8 GB DDR3L RAM with ECC (Error-Correcting Code) for data integrity.
- Communication Interfaces:
- 2 × RJ45 Ethernet ports (CN1, CN2) for network connectivity.
- 2 × RJ45 serial ports (COM3, COM4):
- COM3: RS-232C port with modem control signals.
- COM4: Isolated port for configuration tools.
- I/O Capabilities:
- Dual-channel 100 MS/s 14-bit analog input.
- Dual-channel 100 MS/s 16-bit analog output.
Description
- Redundancy Support: CPU, CEX-Bus, communication interfaces, and S800 I/O redundancy for enhanced system availability.
- Environmental Ratings:
- Operating temperature: -30°C to +70°C.
- Protection class: IP67 (dust-tight, waterproof).
- Electromagnetic shielding for interference resistance.
- Physical Dimensions: 150 × 130 × 200 mm.
- Power Supply: 24 VDC.
Functional Characteristics
- High-Speed Processing: Enables real-time control and data acquisition for time-sensitive operations.
- Modular Design: Simplifies installation, configuration, and maintenance with DIN rail mounting and sliding-locking mechanisms.
- Multimedia Support: Enhanced display resolution and audio engine for media-intensive applications (e.g., gaming, information kiosks).
- Fault Tolerance: Self-diagnostic functions for rapid fault detection and isolation, minimizing downtime.
- Programming Flexibility: Supports structured text (SFC) and ladder logic programming for complex control algorithms.
- Safety Integration: Allows seamless switching between safety and control functions, with independent processors for safety code execution.
Application Scenarios
- Industrial Automation: Controls actuators (e.g., valves, motors) in manufacturing, energy, and petrochemical industries.
- Process Control: Monitors and adjusts tension in paper manufacturing, textile production, and metal rolling to prevent defects.
- Data Acquisition: Collects analog signals (temperature, pressure, flow) for quality assurance in food packaging and battery production.
- Safety Systems: Implements safety instrumented systems (SIS) to prevent hazardous events in oil & gas, chemicals, and nuclear sectors.
- Machine Control: Manages robotic systems and conveyor lines in packaging and automotive industries.
Industry Applications
- Manufacturing: Automation and quality control in automotive, aerospace, and electronics.
- Energy: Wind turbine control, solar panel production, and grid management.
- Metallurgy: Steel rolling mills and material handling systems.
- Petrochemicals: Refinery process monitoring and pipeline control.
- Water Treatment: Pump and valve control for wastewater management.
Advantages
- Durability: Stainless steel housing and IP67 rating ensure long-term reliability in harsh environments.
- Precision: High-resolution analog I/O for accurate measurements.
- Scalability: Supports system expansion and upgrades through modular design.
- Low Maintenance: Self-diagnostics and dust/waterproof construction reduce upkeep costs.
- Compatibility: Integrates with ABB’s DCS, PLC, and Millmate tension control systems, as well as third-party devices via Modbus and Ethernet/IP protocols.
Software and Tools
- Configuration: ABB Ability™ System 800xA for parameter setup and calibration.
- Diagnostics: ABB AssetCare software for remote monitoring and firmware updates (OPC UA compatible).
- Development: Supports NI FlexRIO adapter modules for custom I/O solutions and structured text programming.
