| Category | Specification |
|---|---|
| Model Number | PFXC141, Order Number: 3BSE029997R0001 |
| Product Type | Industrial Junction Box for Pressductor® Load Cell Systems |
| Compatible Devices | ABB Pressductor® load cells (PFTL, PFVL series) and tension electronics (PFEA series) |
| Enclosure Material | High‑grade polycarbonate / metal alloy (corrosion‑resistant) |
| Dimensions | 220 mm × 120 mm × 80 mm (L×W×D) |
| Weight | 2.0 kg (gross) |
| Protection Rating | IP65 (NEMA 4), dust‑tight and water‑resistant |
| Impact Resistance | IK08 (high mechanical durability) |
| Flame Retardance | UL 94 V‑0 (self‑extinguishing) |
| Operating Temperature | -40 °C to +80 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% – 95% RH (non‑condensing) |
| Cable Glands | Pg16, accommodates cables 6–12 mm in diameter |
| Mounting | Wall‑mountable, surface‑mount near load cells |
| Country of Origin | Sweden |
| Certifications | CE, RoHS compliant |
Functional Features
-
Pressductor® System Compatibility
Optimized for ABB’s Pressductor® magnetoelastic load cell technology, ensuring seamless signal matching and transmission between field sensors and tension control units. Preserves low‑impedance AC signal characteristics for maximum immunity to electromagnetic interference (EMI) and ground faults.
-
Long‑Distance Signal Transmission
Enables reliable signal transmission over extended cable runs (up to 30 meters) between load cells and control electronics, eliminating signal degradation and supporting flexible system layout in large production facilities.
-
Centralized Wiring & Cable Management
Provides a dedicated enclosure for terminating and organizing multiple load cell cables, reducing wiring complexity, minimizing signal cross‑talk, and simplifying installation, troubleshooting, and maintenance.
-
Rugged Environmental Protection
IP65‑rated enclosure with IK08 impact resistance safeguards internal connections from dust, moisture, oil, and mechanical shock in harsh industrial environments. Operates reliably across extreme temperature ranges (-40 °C to +80 °C).
-
Easy Installation & Service Access
Compact, wall‑mountable design allows installation directly adjacent to load cells in easily accessible service locations. Pre‑configured cable gland entries (Pg16) support quick, secure cable connections with proper strain relief.
-
High‑Quality Construction & Durability
Manufactured with flame‑retardant (UL 94 V‑0) polycarbonate and corrosion‑resistant materials, ensuring long service life and minimal maintenance in continuous industrial operation.
-
System Integration Flexibility
Fully compatible with ABB’s complete Millmate tension control ecosystem, including PFEA series tension amplifiers and PFTL/PFVL load cells, supporting retrofits and new installations in web‑handling and metal processing lines.
Application Scenarios
-
Paper & Board Manufacturing
Deployed in paper machines, coaters, slitter‑rewinders, and converting lines to connect Pressductor® load cells to tension control systems. Ensures stable tension measurement for high‑speed web processing, reducing breaks and maintaining product quality.
-
Metal Rolling & Processing
Used in steel/aluminum hot/cold rolling mills, slitting lines, and foil production to interface load cells with PFEA tension electronics. Delivers reliable force measurement in electrically noisy environments, supporting precise thickness control and material uniformity.
-
Plastic Film & Extrusion Lines
Integrated into film extrusion, casting, and stretching lines for connecting tension sensors to control units. Maintains accurate tension feedback to prevent web stretching, warping, and defects in thin‑film production.
-
Textile & Nonwoven Production
Applied in weaving, dyeing, and finishing lines to link load cells with tension control systems. Ensures consistent tension measurement for yarns and fabrics, improving product uniformity and reducing manufacturing defects.
-
Packaging & Printing Machinery
Used in flexographic/rotogravure presses and packaging lines to connect tension sensors to control electronics. Supports precise tension regulation for labels, films, and paper webs, ensuring print registration and packaging quality.
-
General Industrial Automation
Utilized in material testing, winding, and web‑handling systems across diverse industries requiring robust, long‑distance sensor‑to‑control connectivity in harsh operating conditions.
