Product Short Description
Technical Specifications
-
Power Supply: 24 V DC ±10 %
-
Analog Input Range: 4–20 mA / 0–10 V, 12–16 bit resolution
-
Long-term Drift: < 0.1 % per year
-
Digital Output: relay contacts, 250 V AC / 30 V DC, 5 A max per contact
-
Isolation: 3.75 kV RMS reinforced between channels and system
-
Operating Temperature: –25 °C to +60 °C
-
Storage Temperature: –40 °C to +70 °C
-
Humidity: 5 %–95 % non-condensing
-
Enclosure: metal, IP65 rated
-
Dimensions: 200 mm × 150 mm × 80 mm
-
Weight: 1.5 kg
Description
Functional Features
-
Dual-role design: analog signal conditioning plus high-current relay outputs in one module
-
Built-in ADC and microprocessor provide sampling, filtering, linearization and amplification for stable, accurate signals
-
Configurable output logic: pulse-width modulation, time delays or on/off patterns set via software
-
Hot-swap capable and supports online parameter changes without system shutdown
-
Comprehensive self-diagnostics: open-circuit, short-circuit and over-range detection with status LEDs
Application Scenarios
-
Industrial automation: drives, motors, valve and actuator control in chemical, petrochemical and food & beverage plants
-
Power generation: excitation systems, turbine auxiliary control and switchgear interface
-
Water & wastewater: pump stations, dosing skids and gate valve automation
-
HVAC & building automation: damper, fan and chiller control loops
-
Test benches & laboratories: signal conditioning and load switching for calibration rigs
