ABB PFSK151 3BSE018876R1 – Signal Processing & Communication Module

Description

• Channels – Base 8 DI / 6 DO, expandable to 142 digital or mixed I/O points via add-on slices
• Processor – Floating-point DSP core (TI C2000 class) with 20 kHz sampling / control loop capability
• Memory – 8 k-step flash EPROM for user program, 8 k-word RAM for data logging
• Analog precision – 0.02 % accuracy, 12-bit resolution on analog channels
• Power – Dual 24 V DC inputs (18–30 V), 5 W typical draw, reverse-polarity protected
• Isolation – 2.5 kV channel-to-system, 1 kV channel-to-channel
• Environment – –50 °C to +70 °C operating, 95 % RH non-condensing, IP65 housing option
• Dimensions – 100 mm × 50 mm × 20 mm core board; rack module 250 mm × 210 mm × 140 mm, 6.5 kg
• MTBF – > 100 000 h at 40 °C

• Ethernet 10/100 Mbit – Modbus TCP, EtherNet/IP, PROFINET IRT
• Serial – RS-232 / RS-485: Modbus RTU, proprietary ABB frames
• Fieldbus – PROFIBUS DP-V1, CANopen, HART pass-through
• Network redundancy – dual media, seamless switch-over < 1 ms
• Time sync – SNTP or GPS for SOE and control loop synchronization

• Real-time DSP – FFT, FIR/IIR filtering, vector control algorithms executed in hardware
• Hot-swap – online module replacement without stopping the rack
• Self-diagnostics – LED fault map, web-based status page, SNMP traps
• Programmability – ladder, C/C++, MATLAB-generated code; IEC 61131-3 compliant
• Data retention – non-volatile flash; configuration survives power loss indefinitely
• Expandability – plug-and-play extension cards for extra I/O, communication or motion axes

• Petrochemical: reactor temperature/pressure cascade control, pump skid monitoring
• Power generation: turbine excitation, generator protection, substation RTU gateway
• Manufacturing: robot trajectory planning, high-speed packaging line coordination
• Water & wastewater: chemical dosing loops, remote pump station telemetry
• Building automation: HVAC optimization, energy metering, lighting control networks
