Technical Specifications
- Core Measurement Parameters:
- Technology: Non-contact pulse laser measurement (TDLAS-based) .
- Measurement Range: 0.3–100 m (horizontal); up to 150 m for positioning applications .
- Accuracy: ±5 mm across the full range .
- Response Time: <1 second for real-time level tracking .
Description
- Physical & Environmental:
- Dimensions: Compact field unit (exact size varies by housing; core optics: ≈80 mm × 80 mm × 25 mm for I/O modules) .
- Weight: 100–150 g (module); ≈5 kg (full system with enclosure) .
- Operating Temperature: -40°C to +60°C (process); -40°C to +85°C (electronics) .
- Process Pressure: -1 to 3 bar .
- Protection Rating: IP67 (standard); IP54 variants for extreme dust/moisture .
- Electrical & Interfaces:
- Power Supply: 18–32V DC (24V DC nominal) .
- Output Signals: 4–20 mA + HART; optional Profibus PA/Foundation Fieldbus .
- Communication: RS-485 Modbus RTU .
- Load Capacity: 600 Ω max. for analog outputs .
Functional Features
- Advanced Laser Technology:
- Measures bulk solids (e.g., coal, grains) and opaque liquids (e.g., oil, sludge) without physical contact .
- Immune to steam, dust, and ambient light interference via adaptive signal processing .
- Robust Design & Usability:
- Heated Optics: Prevents condensation in humid environments .
- Auto-Ranging: Automatically adjusts to container geometry; no manual calibration required .
- Alignment Laser: Integrated visual guide for precise targeting in confined spaces (e.g., silos, reactors) .
- Smart Integration:
- Multi-Protocol Support: Seamless integration with DCS/SCADA via HART, Profibus, or Fieldbus .
- Diagnostics: Built-in self-tests and event logging (>10,000 entries) for predictive maintenance .
Application Scenarios
| Industry | Use Cases | Key Measurement Targets |
|---|---|---|
| Power Generation | • Coal bunker level monitoring • Boiler feedwater tank control |
Bulk solids; high-temperature liquids |
| Oil & Gas | • Crude oil storage tanks • Pipeline leak detection |
Opaque liquids; interface levels |
| Mining & Minerals | • Ore silos • Tailings pond level tracking |
Abrasive solids; slurry mixtures |
| Chemical Processing | • Reactor vessel levels • Acid/alkali storage |
Corrosive liquids; volatile media |
| Food & Beverage | • Grain silos • Fermentation tank control |
Hygienic solid/liquid level tracking |
Installation & Maintenance
- Deployment Guidelines:
- Mounting: Flexible orientation (top/side-mounted); threaded or flange connections (ANSI/DIN standards) .
- Optical Path: Clear line-of-sight required; min. 0.3 m dead zone .
- Preventive Protocols:
- Quarterly: Optical window cleaning with isopropyl alcohol .
- Annual: Signal path validation; output calibration via HART communicator .
- Troubleshooting:
- Signal Loss: Verify target reflectivity (min. 10% for solids) .
- Drift Errors: Check for window fouling or temperature extremes .
Certifications & Support
- Compliance: SIL 2 (IEC 61508), ATEX/IECEx/CSA (Zone 2), CE, RoHS .
- Warranty: 12 months (extendable to 36 months) .
- Global Service: ABB Technical Support with 48-hour critical response .
Specification Conflicts & Clarifications
| Parameter | Conflict Source | Adopted Value | Rationale |
|---|---|---|---|
| Dimensions | 80×80×25 mm vs. larger enclosures | Module vs. system distinction | Core electronics modular; enclosures vary by site |
| IP Rating | IP20 vs. IP67 | IP67 (field) / IP20 (control) | describes I/O module; others field unit |
| Output Protocols | RS-485 only vs. HART/FF | HART/FF standard; RS-485 option | Multiple sources confirm multi-protocol support |
