Product Short Description
Compatibility & Integration
- Hardware Ecosystems:
- ABB Controllers: C300 Series, AC 800M .
- I/O Modules: Hybrid analog/digital FBMs; Allen Bradley 1794 series .
- Software Tools:
- ABB Automation Builder: Logic programming and diagnostics .
- System 1 (Bently Nevada): Vibration monitoring integration .
Description
Technical Specifications
| Category | Parameters |
|---|---|
| Physical Dimensions | • Main Unit: 120 mm × 50 mm × 165 mm (L × W × H) • I/O Submodule: 22.5 mm × 60 mm × 101.5 mm (H × W × D) |
| Weight | 0.5 kg |
| Electrical Ratings | • Input Voltage: 24 V DC ±10% (standard); 220 V AC (configurable) • Output Voltage: 0–10 V DC / 0–5 V DC • Max Load Current: 5 A |
| I/O Capabilities | • Analog I/O: 12-bit resolution, ±0.1% accuracy • Digital I/O: 16 DI + 16 DO (configurable) |
| Communication | • Protocols: Modbus RTU/TCP, Ethernet/IP, PROFIBUS • Interfaces: RS-232, RS-485, Ethernet |
| Environmental | • Operating Temp: -20°C to +60°C • Protection Rating: IP54 (main unit); IP20 (submodules) |
| Processing & Memory | • CPU: High-speed 32-bit RISC processor • Memory: 256 KB RAM + 512 KB Flash (expandable) |
Functional Features
- High-Performance Control
- Executes complex algorithms (e.g., PID control, motion logic) via IEC 61131-3 languages (Ladder Diagram, Structured Text) .
- Real-time data acquisition at 1 MHz pulse counting for precision monitoring .
- Modular & Scalable Architecture
- Hot-swappable I/O submodules (e.g., analog, digital, temperature) for field upgrades .
- Compatible with ABB Advance Optima series and third-party PLCs (Siemens S7-1500, Honeywell Experion) .
- Robust Industrial Design
- Signal Isolation: 500 V electrical isolation to prevent EMI interference .
- Dual Watchdog Timer: Auto-resets microprocessor during hangs .
- Conformal Coating: Resists chemicals/humidity in harsh environments .
- Smart Connectivity
- Remote configuration via Ethernet/OPC; cloud-SCADA integration (Ignition, WinCC) .
- DCON and Modbus RTU protocols over RS-485 (115.2 kbps) for legacy systems .
Application Scenarios
| Industry | Use Cases | Key Functions |
|---|---|---|
| Process Industries | • Chemical reactor pressure/temperature control • Pharmaceutical batch process monitoring |
Real-time analog I/O tracking; SIL 2 safety interlocks |
| Energy Management | • Power plant turbine control (GE Mark VIe integration) • Grid load balancing |
16-bit precision measurement; fault logging |
| Water/Wastewater | • Pump station flow control • Sewage treatment parameter monitoring |
Modbus RTU integration; leak detection |
| Manufacturing | • Robotic welding line synchronization (KUKA/PROFINET) • Automated assembly I/O signaling |
High-speed digital I/O; motion control logic |
| Building Automation | • HVAC/lighting control in smart buildings • Security system integration |
Multi-protocol support; remote diagnostics |
Installation & Maintenance
- Deployment Guidelines
- Mounting: DIN rail (EN 60715) with ≥50 mm ventilation clearance .
- Cabling: Shielded twisted pairs for analog signals; fiber optics in high-EMI zones .
- Preventive Maintenance
- Quarterly: Optical sensor calibration; connector cleaning .
- Annual: Firmware updates via Automation Builder; I/O channel validation .
- Troubleshooting
- I/O Drift: Recalibrate using ABB Service Toolkit .
- Network Failure: Verify RS-485 termination (120 Ω) or IP conflicts .
Certifications & Support
- Compliance: SIL 2 (IEC 61508), CE, RoHS, ATEX Zone 2 .
- Warranty: 12–36 months (extendable) .
- Global Service: ABB-certified engineers; 48-hour critical response .
Specification Conflicts Clarified
| Parameter | Conflict Sources | Adopted Value | Rationale |
|---|---|---|---|
| Input Voltage | 24V DC vs. 220V AC | Dual-range support | confirm configurable inputs |
| Dimensions | 120×50×165 mm vs. 22.5×60×101.5 mm | Two variants (main unit vs. I/O module) | Modular design validated in |
| IP Rating | IP54 vs. IP20 | IP54 (main); IP20 (submodules) | Submodule specs in |
