ABB ICSE08B5 Remote Analog Input Unit

Description

Technical Specifications

• Product Type: Remote Analog Input Unit
• Series: ABB Procontic CS31
• Manufacturer: ABB
• Supply Voltage: 24 VDC

• Number of Input Channels: 8 independent analog inputs
• Resolution: 12‑bit high‑precision conversion
• Input Signal Types: Configurable per channel – voltage or current
• Voltage Input Ranges: 0–10 V, -10–+10 V
• Current Input Ranges: 0–20 mA, 4–20 mA
• Accuracy: ±0.2% of full scale

• Galvanic Isolation: 1500 VAC between field circuits and system
• Response Time: ≤ 5 ms
• Power Consumption: ≤ 2 W

• Operating Temperature: -25 °C to +70 °C
• Storage Temperature: -40 °C to +85 °C
• Humidity: 5–95% RH, non‑condensing
• Protection Rating: IP20
• Mounting: DIN rail mount
• Terminals: Pluggable screw terminals
• Dimensions: Standard CS31 remote unit form factor
• Weight: Approx. 0.28–0.5 kg

• Complies with industrial EMC standards
• Complies with IEC 61131‑2 requirements

Key Features

• 8 independent 12‑bit analog input channels support simultaneous, high‑accuracy data collection from multiple field sensors.
• Per‑channel DIP‑switch configuration between voltage and current modes simplifies field wiring and adaptation.

• Full galvanic isolation eliminates ground loops and protects the control system from field‑side electrical interference.
• Industrial‑grade EMC design ensures stable operation in environments with high electromagnetic interference.

• Native plug‑and‑play compatibility with ABB Procontic CS31 central units and remote bases.
• Integrated microprocessor handles local signal conditioning, conversion, and diagnostics to reduce CPU load.

• Extended operating temperature range and rugged construction for reliable performance in demanding environments.
• Pluggable terminals and compact modular design speed installation, commissioning, and maintenance.

• Onboard monitoring of power, communication, and channel status supports fast troubleshooting.
• LED indicators provide real‑time visibility of module status and signal integrity.

Application Scenarios

• Continuous monitoring of temperature, pressure, flow, and level in chemical, petrochemical, and pharmaceutical facilities.
• Signal acquisition from analyzers, transmitters, and regulatory instruments in closed‑loop control systems.

• Analog feedback from position sensors, load cells, and speed transducers in assembly lines, robotics, and machine tools.
• Process monitoring and quality control in packaging, material handling, and forming machinery.

• Data collection from voltage transducers, current transformers, and temperature sensors in power plants and substations.
• Monitoring of generator sets, transformers, and distribution equipment.

• Analog signal acquisition from wellhead sensors, pipeline pressure transmitters, and tank level instruments.
• Integration into remote terminal units for offshore and onshore production facilities.

• Monitoring of flow meters, pH sensors, conductivity probes, and liquid‑level transmitters.
• Automated control of pumping, dosing, and filtration processes.

• Signal collection from temperature, pressure, and vibration sensors in smelting, rolling, and crushing equipment.
• Condition monitoring and predictive maintenance for heavy industrial machinery.

• Environmental monitoring using temperature, humidity, and air‑quality sensors.
• Integration into HVAC, energy management, and utility monitoring systems.
