Product Short Description
- Electrical Ratings:
- Rated Voltage: 250 V AC or 124 V DC
- Rated Current: 6 A
- Input Voltage: 27 V DC
- Output Voltage: 8 V DC
- Mechanical Specifications:
- Dimensions: 110 mm × 20 mm × 35 mm
- Weight: Approximately 200 g
- Mechanical Life: 10 million cycles
- Electrical Life: 100,000 cycles
Description
- Environmental Tolerance:
- Operating Temperature: -40°C to +85°C
- Connectivity:
- Communication Protocols: Supports Modbus and industrial Ethernet for seamless integration with DCS/SCADA systems.
- Ports: RS485 (for remote communication) and RS232 (for local configuration).
Functional Features
- Automatic Synchronization: Monitors grid voltage and frequency, automatically initiating generator connection when conditions are met.
- Synchronization Protection: Detects faults like phase mismatch or voltage imbalance to prevent equipment damage.
- Signal Processing: Enhances system responsiveness in PLC setups by filtering and amplifying input signals.
- Control Outputs: Provides 6 form-C relays (10 A/30–250 VAC/DC) for tripping or sequencing operations.
- User Interface: Features a 40-character vacuum fluorescent display and keypad for local configuration and real-time monitoring.
- Programmability: Allows customization of control logic, setpoints, and event thresholds via EnerVista software.
- Durability: Built with industrial-grade materials to withstand vibration, temperature extremes, and electrical interference.
Application Scenarios
- Power Plants: Manages generator start-up, grid connection, and black-start procedures to ensure stable operation.
- Substations: Enhances grid stability by synchronizing distributed energy resources (e.g., solar, wind) with the main network.
- Oil and Gas: Protects compressors and pumps from voltage fluctuations during synchronization, reducing downtime.
- Manufacturing: Integrates with PLC systems to control motors, conveyors, and other critical equipment in factories.
- Renewable Energy: Facilitates seamless integration of inverter-based generators into weak grids.
Design Advantages
- Compact Form Factor: Space-saving design simplifies installation in control panels.
- Hot-Swapping: Enables module replacement without powering down the system, minimizing operational disruption.
- Global Support: Backed by ABB’s technical expertise and service network for timely assistance.
- Cost Efficiency: Reduces wiring complexity and maintenance costs through integrated functionality.
