Product Overview
The ABB FENA-11 is a high-performance single-port Ethernet adapter module designed to connect ABB variable frequency drives, converters, and inverters to industrial Ethernet networks . As a member of ABB’s F-series fieldbus adapter family, this compact plug-in module enables seamless communication between ABB drives and higher-level automation systems through multiple industrial Ethernet protocols . The FENA-11 supports PROFINET IO, EtherNet/IP, and Modbus TCP protocols, with protocol selection accomplished through a single drive parameter, providing exceptional flexibility for system integration .
Description
Technical Specifications
The ABB FENA-11 features comprehensive technical specifications that reflect its advanced engineering and versatile application capabilities:
| Parameter | Specification |
|---|---|
| Product Type | Ethernet Adapter Module |
| Model Number | FENA-11 |
| Part Number | 3ABD0000089107 |
| Supported Protocols | PROFINET IO (DP-V1, PROFIdrive), EtherNet/IP (ODVA compliant), Modbus TCP |
| Data Transfer Rate | 10/100 Mbit/s with auto-negotiation |
| Connector Type | 1 × RJ-45 Ethernet port |
| Physical Interface | 20-pin connector for drive backplane integration |
| Power Supply | From drive backplane, no external supply required |
| Mounting | Plug-in module inside drive cabinet with locking mechanism and grounding screw |
| Mounting Screw Torque | 0.8 Nm using Torx TX10 screwdriver |
| Diagnostic LEDs | Status indicators for module operation and network communication |
| MAC ID | Printed on module label for network identification |
| Dimensions (approx.) | 110 mm × 11 mm × 11 mm (some sources indicate larger dimensions for complete assembly) |
| Weight | Approximately 1 kg (complete packaged module) |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 |
| Country of Origin | Sweden / China |
| Compliance | IEEE 802.3 and IEEE 802.3u Ethernet standards |
Protocol-Specific Support Features
| Protocol | Supported Features |
|---|---|
| PROFINET IO | DP-V1 communication, PROFIdrive profile, ABB Drives profile, transparent modes for 16-bit and 32-bit words, GSDML file support |
| EtherNet/IP | ODVA AC/DC Drive profile, ABB Drives profile, Transparent profile, explicit and implicit messaging, EDS file support |
| Modbus TCP | ABB Drives profile, Transparent profile, read/write single and multiple register function codes, Modbus over UDP support |
Key Features and Advantages
The ABB FENA-11 is distinguished by its comprehensive feature set, engineered to meet the rigorous demands of modern industrial drive communication.
Multi-Protocol Flexibility
The FENA-11 supports three major industrial Ethernet protocols within a single hardware platform, eliminating the need for multiple adapter variants and simplifying inventory management . Protocol selection is accomplished through a single drive parameter, allowing the same module to be reconfigured for different network requirements without hardware changes . This multi-protocol capability ensures compatibility with a wide range of automation systems including Siemens, Rockwell Automation, and other major PLC platforms.
Seamless Drive Integration
The module plugs directly into a dedicated option slot on compatible ABB drives, featuring a secure three-point retention system comprising plastic alignment pins, a locking mechanism, and a mounting screw . The mounting screw serves a dual purpose by also creating an electrical connection between the module and the drive frame for proper cable shield termination, ensuring electromagnetic compatibility and signal integrity .
Compact Space-Saving Design
The FENA-11’s compact form factor integrates entirely within the drive enclosure, consuming no additional panel space and maintaining the drive’s original footprint . This internal mounting protects the module from environmental contaminants and simplifies cabinet layout by eliminating external enclosures or DIN rail mounting requirements.
Comprehensive Communication Profiles
The module supports multiple communication profiles for each protocol, providing flexibility in how drive data is structured and exchanged :
-
PROFIdrive Profile: Standardized drive profile for PROFINET networks ensuring interoperability with various automation systems
-
ODVA AC/DC Drive Profile: Standardized drive profile for EtherNet/IP networks compliant with ODVA specifications
-
ABB Drives Profile: ABB-specific enhanced profile providing access to advanced drive features and parameters
-
Transparent Profile: Allows transmission of non-standard or user-defined data structures for customized applications
