Product Short Description
Technical Specifications:
- Input/Output Functionality:
- Configurable digital input/output channels (specific quantity varies by configuration).
- Supports 24V DC signal levels (1 = +24V, 0 = 0V).
- Counting Performance:
- Sampling Rate: 1 GSa/s (real-time) and 25 GSa/s (equivalent).
- Memory Depth: 25,000 data points.
- Bandwidth: 100 MHz (-3 dB).
- Sensitivity: 2 mV/div to 5 V/div (1-2-5 step adjustment).
- Accuracy: ±(3% × |read value| + 0.05 div × volts/div + 0.8 mV).
Description
- Electrical Specifications:
- Input Voltage: 110V–380V AC.
- Current: 1A–30A.
- Power: 5W–130W.
- Input Impedance: 1 MΩ ±2%, ~16 pF.
- Maximum Input: 300V (DC + AC peak), CAT II.
- Communication:
- Supports USB HOST/DEVICE for external storage and printers.
- Optional AC/DC power operation modes.
- Ethernet interface for network integration.
- RS485 communication protocol.
- Mechanical Design:
- Dimensions: Approx. 170 mm × 170 mm (L × W).
- Weight: 0.9–2.8 kg (depending on configuration).
- Protection Class: IP30/IP45 (varies by variant).
- Structure: Drawer-type design for easy installation.
- Environmental Ratings:
- Operating Temperature: -15°C to +60°C.
- Relative Humidity: 5%–90% (non-condensing).
Functional Features:
- High Precision: Utilizes high-speed counting technology for accurate pulse signal processing.
- Flexible Configuration: Users can adjust counting modes, input channels, and parameters to suit diverse applications.
- High Reliability: Designed to meet industrial standards (e.g., IEC 61131-3) for long-term operation in harsh environments.
- Easy Integration: Offers multiple communication interfaces (Ethernet, RS485, USB) for seamless data exchange with other devices.
- Remote Monitoring: Supports diagnostics and maintenance via network connections.
- Safety Compliance: Adheres to UL, CE, and other international safety standards.
- User-Friendly Interface: Features a 5.6-inch TFT color LCD screen for intuitive operation.
Application Scenarios:
- Manufacturing Automation: Controls conveyors, robots, and packaging machinery.
- Process Control: Monitors valves, pumps, and sensors in chemical and water treatment plants.
- Renewable Energy: Regulates solar inverters and wind turbine converters.
- Power Generation: Manages DCS (Distributed Control System) excitation systems.
- Building Automation: Oversees HVAC, lighting, and security systems.
- Machine Optimization: Enables real-time machine learning inference for quality control (e.g., via TwinCAT integration).
Key Advantages:
- Scalability: Adapts to small-scale systems or large industrial networks.
- Durability: Withstands vibration, EMI, and temperature extremes.
- Cost-Effectiveness: Reduces downtime and maintenance costs through reliable performance.
- Global Support: Backed by ABB’s technical service and firmware updates.
