Product Short Description
Technical Specifications
- Input Channels: 16 channels, divided into two independent isolated groups of 8 channels each.
- Input Voltage: Supports 18 V DC to 30 V DC (standard 24 V DC).
- Input Current: 6 mA at 24 V DC.
- Isolation: Each group features voltage monitoring inputs to detect voltage loss and generate error signals.
- Response Time: ≤ 2 ms for rapid signal processing.
- Operating Temperature: -40 °C to +70 °C (-40 °F to +158 °F).
- Storage Temperature: -60 °C to +125 °C (-76 °F to +257 °F).
- Mounting: DIN rail installation for compact deployment.
- Communication: Supports PROFIBUS DP, PROFINET IO, CANopen, or DeviceNet via optional adapters.
- Certifications: Complies with IEC 61131-2, IEC 61508 (SIL2/SIL3), and ISO 13849 (PL e) for functional safety.
Description
Key Features
- High Reliability: Industrial-grade components and rigorous testing ensure stable operation in harsh environments.
- Flexible Configuration: Software-configurable channels adapt to diverse signal types and applications.
- Signal Integrity: Advanced filtering (2/4/8/16 ms selectable) and anti-interference design minimize noise for accurate signal transmission.
- Diagnostics: LED indicators and voltage monitoring provide real-time status monitoring and error detection.
- Safety Compliance: Supports safety-critical applications with redundant protection and international safety standards.
- Seamless Integration: Compatible with ABB’s AC500 PLCs, 800xA DCS, and third-party control systems.
- Hot-Swappable Design: Modules can be replaced without powering down the system, reducing downtime.
Application Scenarios
- Power and Energy:
- Monitors circuit breakers and switch status in substations.
- Captures signals from boiler, turbine, and cooling systems in power plants.
- Enables remote signal monitoring and control in smart grids.
- Process Industries:
- Tracks pipeline pressure and valve status in oil and gas facilities.
- Collects equipment start/stop and alarm signals in chemical and pharmaceutical plants.
- Monitors blast furnace and rolling mill signals in metallurgical processes.
- Manufacturing and Factory Automation:
- Collects switch signals from robots and conveyor systems in automotive manufacturing.
- Controls production lines in electronics manufacturing.
- Monitors conveyor belts and AGV (Automated Guided Vehicle) status in logistics and warehousing.
- Rail Transportation:
- Monitors signal lights, rail switches, and door status in trains.
- Collects power system status data in metro and light rail systems.
- Water Treatment and Environmental Protection:
- Monitors pump stations, valves, and alarm signals in wastewater treatment plants.
- Tracks liquid level, flow, and pressure data in water treatment facilities.
Industries
- Oil and Gas: Pipeline monitoring, wellhead control, and refinery operations.
- Power Generation: Grid stability management, turbine control, and transformer protection.
- Metallurgy: Blast furnace automation, rolling mill control, and material handling systems.
- Pharmaceuticals: Cleanroom environment monitoring and batch process control.
- Food and Beverage: Production line monitoring and packaging equipment control.
