Product Short Description
Technical Specifications:
- Voltage Rating: 2.3 kV, 3.3 kV, 4.16 kV, 6 kV, 6.6 kV, 10 kV, 11 kV, 13.8 kV.
- Power Rating: Up to 15 MW (dependent on voltage and motor configuration).
- Control Technology: Direct Torque Control (DTC) for precise motor regulation.
- Cooling Method: Air-cooled or liquid-cooled options.
- Enclosure: IP54 or IP55 rated for dust and water resistance.
- Operating Temperature: -20°C to +50°C (standard), with extended ranges available.
- Altitude: Up to 1,000 meters above sea level (higher altitudes require derating).
- Communication Protocols: Supports PROFIBUS, Modbus, Ethernet/IP, and OPC UA for industrial network integration.
- Control Interface: Intuitive HMI with touchscreen display for configuration and monitoring.
- Regulatory Compliance: Meets IEC, UL, and CSA standards for global applicability.
Description
Functional Characteristics:
- High Precision Control: DTC technology ensures accurate speed and torque regulation without external encoders.
- Energy Efficiency: Reduces motor energy consumption by up to 30% through optimized speed control.
- Reliability: Robust design withstands voltage dips, harmonics, and transient disturbances.
- Remote Monitoring: Enables real-time diagnostics and predictive maintenance via integrated sensors.
- Flexibility: Adaptable to various motor types (synchronous, asynchronous, induction) and applications.
- Ease of Integration: Compatible with standard industrial protocols and PLC systems.
- Safety Features: Includes overcurrent, overvoltage, and thermal protection to safeguard motors.
Application Scenarios:
- Oil and Gas: Controls pumps, compressors, and blowout preventers in upstream and downstream operations.
- Power Generation: Regulates turbines, generators, and cooling systems in thermal and hydroelectric plants.
- Mining: Powers conveyors, crushers, and ventilation systems in underground and surface mines.
- Water and Wastewater: Manages pumps, aerators, and filtration systems in treatment plants.
- Metals and Mining: Optimizes rolling mills, blast furnaces, and material handling equipment.
- Cement: Controls crushers, mills, and kilns in cement production.
- Marine: Drives propulsion systems, side thrusters, and deck cranes on ships.
- Pulp and Paper: Regulates papermaking machines, dryers, and conveyors.
Key Advantages:
- Energy Savings: Reduces operational costs through optimized motor control.
- Enhanced Productivity: Minimizes downtime with predictive maintenance and real-time diagnostics.
- Global Support: ABB provides worldwide service, lifecycle management, and application expertise.
- Scalability: Adaptable to diverse industrial requirements, from small-scale to large-scale systems.
- Safety and Compliance: Meets international standards for reliability and operator safety.
