Product Short Description
Product Identity
Type: High-precision analog output module for distributed control systems (DCS) and PLCs.
Type: High-precision analog output module for distributed control systems (DCS) and PLCs.
Technical Specifications
-
Output Channels: 8
-
Output Ranges: 0–20 mA, 4–20 mA, 0–10 V, ±10 V (software-selectable)
-
Resolution: 16 bit
-
Accuracy: ±0.1 % of full scale
-
Isolation: 500 V DC channel-to-bus
-
Power Supply: 24 V DC nominal
-
Operating Temperature: –25 °C to +70 °C
-
Communication: PROFIBUS DP, Modbus TCP/IP, EtherNet/IP (protocol depends on system configuration)
Description
Functional Features
-
Configurable signal types and ranges adapt to valves, actuators, drives, and other field devices.
-
Channel-level diagnostics detect wire break, short circuit, and over-range conditions, reducing troubleshooting time .
-
Galvanic isolation protects the control system from ground loops and electrical noise.
-
Hot-swap capable and supports online parameter changes without process interruption.
Application Scenarios
-
Chemical plants: precise dosing of reagents via control-valve current signals.
-
Oil & gas pipelines: remote adjustment of pressure and flow control valves .
-
Power generation: steam-turbine governor and boiler actuator control.
-
Water & wastewater: regulating chemical-feed pumps and valve positioning.
-
Pharmaceutical reactors: maintaining tight temperature and pressure set-points .
