ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101

Description

Technical Specifications

• 5SHY4045L0006
  • Voltage Rating: 3300 V DC (typical)
  • Current Rating: Hundreds of amperes (specific values depend on configuration)
  • Switching Frequency: Up to 10 kHz
  • Thermal Resistance: ≤0.08 °C/W
  • Operating Temperature: -40°C to +85°C
  • Weight: ~3.7 kg
  • Dimensions: 24.5 × 14.5 × 3.2 cm or 20 × 15 × 10 cm
• 3BHB030310R0001
  • Control Voltage: 24 V DC (typical)
  • Communication: Supports ABB proprietary protocols and standard industrial protocols
  • System Compatibility: ACS5000/ACS6000 series medium-voltage drives
  • Installation: Modular design for cabinet or system integration
  • Voltage Levels: 6 kV / 11 kV medium-voltage systems
• 3BHE039203R0101
  • Voltage Rating: High-voltage (specific values depend on application)
  • Current Rating: High-current (specific values depend on application)
  • Protection: Overcurrent, overvoltage, and thermal shutdown
  • Thermal Management: Optimized for high-power applications
• GVC736CE101
  • Voltage Rating: High-voltage (specific values depend on application)
  • Current Rating: High-current (specific values depend on application)
  • Isolation: 4.5 kV input/output isolation
  • Thermal Resistance: ≤0.08 °C/W
  • Weight: ~500 g

Functional Characteristics

• 5SHY4045L0006
  • High Power Density: Enables compact designs for medium-voltage drives.
  • Fast Switching: Reduces losses and improves efficiency.
  • Robust Protection: Built-in safeguards against overcurrent, overvoltage, and thermal runaway.
  • Modular Design: Supports parallel and series configurations for scalable power systems.
• 3BHB030310R0001
  • Grid Isolation: Manages power connections for safe system operation.
  • Fault Protection: Ensures rapid disconnection during abnormalities.
  • Remote Control: Enables centralized management of power systems.
• 3BHE039203R0101
  • High Current Tolerance: Suitable for industrial motor control and power conversion.
  • Thermal Stability: Designed for long-term operation in harsh environments.
  • Diagnostic Capabilities: Real-time monitoring of electrical parameters.
• GVC736CE101
  • High Efficiency: >98% efficiency under full load.
  • Dynamic Response: Supports fast switching for grid stability.
  • Scalability: Adaptable to multi-megawatt applications.

Application Scenarios

• 5SHY4045L0006
  • Industrial Drives: Powers motors in pumps, fans, compressors, and CNC machines.
  • Renewable Energy: Integrates with wind turbine converters and solar inverters.
  • High-Voltage DC Transmission (HVDC): Converts AC to DC for efficient long-distance power transmission.
  • Electric Vehicles: Drives traction inverters for buses and trains.
• 3BHB030310R0001
  • Medium-Voltage Drives: Controls power in ACS5000/ACS6000 series drives.
  • Mining and Cement: Powers high-power motors in crushers and conveyors.
  • Wind Power: Manages grid connections in wind farms.
• 3BHE039203R0101
  • High-Voltage Rectifiers: Used in electrolytic aluminum and arc furnace power supplies.
  • Grid Stability: Supports FACTS devices for voltage and harmonic control.
  • Power Transmission: Enables efficient HVDC energy transfer.
• GVC736CE101
  • Synchronous Motor Control: Provides adjustable excitation current for generators.
  • FACTS Systems: Balances voltage fluctuations and suppresses harmonics.
  • Data Centers: Powers uninterruptible power supplies (UPS) with fast switching.

Key Advantages

• 5SHY4045L0006: Combines high efficiency (>98%) with robust thermal management.
• 3BHB030310R0001: Ensures reliable grid isolation and fault protection.
• 3BHE039203R0101: Offers high current tolerance and diagnostic capabilities.
• GVC736CE101: Provides dynamic response and scalability for grid applications.

Certifications

• All modules comply with IEC 61800-5-1 (safety) and IEC 62477-1 (EMC).
• UL, CE, and CCC certified for global market compliance.
