Product Short Description
- Input Voltage: Three-phase AC 380-480 V (±15%), 50/60 Hz
- Output Voltage: DC 532-670 V (adjustable for specific applications)
- Rated Power: 75 kW (scalable to meet higher demands)
- Efficiency: Up to 94% (double conversion mode), 98.7% (eBoost mode)
- Cooling Method: Forced air cooling for optimal thermal management
- Protection Class: IP20 (front panel)
- Operating Temperature: -20°C to +60°C (design for extreme environments)
- Dimensions: Compact form factor for easy integration into control cabinets
- Weight: Approximately 10-20 kg (depending on configuration)
- Communication: Supports RS232, SNMP, Modbus IP, RS485, and BacNet IP for seamless integration with SCADA/PLC systems
Description
Functional Features
- High Energy Efficiency: Reduces energy consumption and operational costs through advanced power conversion technology.
- Comprehensive Protection:
- Overload, overvoltage, and overtemperature protection ensure system safety.
- Short-circuit protection with automatic recovery.
- Compact and Durable Design:
- Space-saving dimensions for installation in limited spaces.
- Industrial-grade components for long-term reliability in harsh conditions.
- Flexible Input Range: Adapts to global power grids (380-480 V AC), supporting international applications.
- Remote Monitoring and Control:
- Real-time status updates via communication interfaces.
- Programmable signals for customized operation.
- User-Friendly Interface:
- Large LCD display for easy parameter visualization.
- Intuitive controls for quick configuration.
Application Scenarios
- Industrial Automation: Powers PLC controllers (e.g., ABB AC500 series) in manufacturing lines, ensuring uninterrupted operation of motors, conveyors, and robotic systems.
- Process Control: Supplies stable power to sensors and actuators in chemical plants, refineries, and water treatment facilities.
- Energy Management: Integrates with renewable energy systems (e.g., solar inverters) for efficient power distribution.
- Building Automation: Provides reliable power to HVAC systems, lighting controls, and security equipment in smart buildings.
- Transportation: Supports signaling and control systems in railways and metros for safe and efficient operations.
Key Advantages
- Cost Efficiency: Lowers energy bills and maintenance expenses through high efficiency and durable design.
- Scalability: Modular architecture allows easy expansion for future power demands.
- Global Compliance: Meets international standards (e.g., CE, IEC) for safety and performance.
- 24/7 Reliability: Designed for continuous operation in mission-critical applications.
- Expert Support: Backed by ABB’s global service network for technical assistance and spare parts.
