Product Short Description
Technical Specifications:
- Voltage Rating: Up to 1700V DC (varies by configuration).
- Current Rating: Continuous current handling up to 1000A (peak currents supported).
- Power Density: Optimized for compact installations with high efficiency (>98%).
- Thermal Design: Liquid-cooled or forced-air cooling options for temperature management.
- Switching Frequency: Supports frequencies up to 20kHz for precise control.
- Protection Features: Overcurrent, overvoltage, and thermal shutdown protection.
- Mechanical Design: IP54-rated enclosure (dust and water-resistant).
- Dimensions: Standardized form factor for easy integration (e.g., 300 mm × 200 mm × 100 mm).
- Weight: Approx. 5–15 kg (depends on cooling method).
- Certifications: CE, UL, and IEC 61800-5-1 compliance for drive systems.
Description
Functional Features:
- High Efficiency: Minimizes power losses during conversion (e.g., AC-to-DC or DC-to-AC).
- Dynamic Response: Fast switching capabilities for stable motor control or grid synchronization.
- Modular Architecture: Enables parallel operation with other modules for scalability.
- Diagnostics: Built-in sensors for real-time monitoring of voltage, current, and temperature.
- Compatibility: Works seamlessly with ABB’s drive controllers (e.g., ACS880, ACS6000 series).
- Long Lifespan: Designed for >100,000 hours of operation under rated conditions.
Application Scenarios:
- Industrial Drives:
- Motor control for pumps, fans, and compressors.
- High-torque applications in mining and metallurgy.
- Renewable Energy:
- Solar inverter systems for photovoltaic plants.
- Wind turbine pitch and yaw control.
- Power Grid:
- Static VAR compensators (SVCs) for reactive power management.
- High-voltage DC (HVDC) transmission systems.
- Transportation:
- Electric vehicle (EV) charging infrastructure.
- Railway traction power supplies.
Key Advantages:
- Reliability: Proven in harsh industrial and outdoor environments.
- Energy Savings: Reduces operational costs through high efficiency.
- Flexibility: Adaptable to various voltage and current requirements.
- Global Support: Backed by ABB’s technical service and spare parts availability.
Industry Standards Compliance:
- Meets IEC 61800-3 (adjustable speed electrical power drive systems).
- Complies with IEEE 1547 (interconnection standards for distributed resources).
- Adheres to UL 1741 (inverter safety standards).
