Product Short Description
Technical Specifications:
- Communication Protocols:
- Supports 2x EtherCAT or 1x Sercos 3 + 1x EtherCAT for real-time master control.
- Equipped with multiple fiber-optic interfaces for high-speed, stable data transmission.
- Connectivity:
- Modular design allows flexible attachment of 1, 2, or 3-axis controllers on the right side.
- Compatible with MODBUS, PROFIBUS, and other industrial networks via integrated gateways.
- Safety Features:
- Optional programmable safety controller with onboard safety I/O for applications like safe PLC, safe motion, and safe robotics.
- Supports safety standards such as IEC 61508 and ISO 13849.
Description
- Configuration Interface:
- Two-line display for rapid setup and diagnostics.
- Drag-and-drop linking of inputs/outputs to safety logic.
Functional Features:
- High-Speed Performance:
- Real-time processing ensures minimal latency in multi-axis synchronization, critical for applications like printing, packaging, and material handling.
- Redundancy Support:
- Dual-channel configurations enhance system reliability in mission-critical environments.
- Remote Management:
- Enables remote monitoring and operation via SCADA integration or dedicated software tools.
- Scalability:
- Modular architecture allows easy expansion of I/O channels and functionalities as system requirements evolve.
- Modular architecture allows easy expansion of I/O channels and functionalities as system requirements evolve.
Application Scenarios:
- Industrial Automation:
- Controls multi-robot cells, CNC machines, and assembly lines with high precision.
- Power Electronics:
- Regulates voltage/current in systems like electric arc furnaces, induction heaters, and power converters.
- Motion Control:
- Manages synchronized motion in applications such as gearbox alignment, cam disk synchronization, and print mark correction.
- Renewable Energy:
- Optimizes performance in solar inverters, wind turbine converters, and energy storage systems.
- Safety-Critical Systems:
- Implements fail-safe operations in sectors like automotive manufacturing, chemical processing, and nuclear power.
Key Advantages:
- Compact Design: Combines controller and safety functions in a single module, saving space and reducing cabling complexity.
- High Reliability: Built with industrial-grade components to withstand harsh environments (e.g., vibrations, temperature extremes).
- Ease of Use: Intuitive configuration tools and diagnostics simplify setup and troubleshooting.
- Global Support: Backed by ABB’s worldwide service network and lifecycle management services.
