Smart I/O module for ABB Advant Controller 400 series PLCs, combining 16 digital inputs and 16 digital outputs in one compact board . -
Technical Specifications
-
-
-
Inputs: 16 isolated digital inputs, 0 – 30 VDC range, compatible with dry-contact, NPN/PNP sensors or 24 VDC signals
-
Outputs: 16 isolated digital outputs, each capable of switching up to 2 A at 30 VDC, short-circuit protected
-
Description
-
Communication: High-speed RS-232/RS-485 serial link to PLC backplane; optional Ethernet via expansion port
-
Power Supply: 12 – 48 VDC input, 5 VDC regulated output (max 10 A), efficiency > 90 %
-
Physical: 170 mm × 105 mm × 32 mm, 120 g, DIN-rail or PCB mount
-
Environment: –20 °C to +50 °C operating, –40 °C to +70 °C storage, 5 % – 95 % RH non-condensing .
-
Functional Features
-
Isolation: 1 kV between field, logic and supply circuits
-
Diagnostics: Self-test, event logging, real-time status LEDs per channel
-
Hot-swap: Supported under power for maintenance without stopping the rack
-
Configurable I/O: Each channel programmable as input or output via software
-
Modular Expansion: Up to 32 boards per rack for 1024 I/O points total .
-
Typical Applications
-
Industrial automation: motor starters, valve positioners, sensor interfaces
-
Process control: level switches, limit switches, alarm annunciators
-
Energy: generator field contactors, breaker status, turbine auxiliary systems
-
Packaging & material handling: high-speed counting, conveyor interlocks .
-
Status
Product officially discontinued; replacements and spares continue to be available through ABB service channels .
