The ABB 07KT98C (GJR5253100R028) is a robust, industrial‑grade central processing unit designed for the ABB AC900 and AC31 series programmable logic controller systems. It serves as the core control unit for complex industrial automation processes, delivering high‑speed processing, extensive I/O handling, and reliable communication capabilities. Built with a 64‑bit multi‑core RISC processor, this CPU module ensures precise real‑time control, data acquisition, and system monitoring in demanding industrial environments. It supports seamless integration with ABB’s automation platforms and third‑party devices via multiple communication protocols, making it ideal for mission‑critical process control applications.
Description
Technical Specifications
Core Processing Parameters
- Processor: 64‑bit multi‑core RISC processor operating at 1.2 GHz
- Program Memory: 2 MB dedicated user program storage
- Data Memory: 1 MB non‑volatile data storage for process variables
- Instruction Execution Speed: 0.1 ms per 1000 instructions for ultra‑fast processing
- I/O Processing Capacity: Manages up to 2048 digital I/O points and 512 analog I/O points
- Scan Cycle: Configurable scan cycles for optimized process control
Communication Interfaces
- Ethernet Protocols: PROFINET, EtherNet/IP, Modbus TCP/IP
- Serial Protocols: RS485, Modbus RTU
- Fieldbus Support: CS31, ARCNET for local I/O expansion
- Communication Ports: Dual Ethernet ports, 1 RS485 port, 1 ARCNET port
- Data Transfer Rate: Up to 100 Mbps for Ethernet communication
Electrical & Power Parameters
- Power Supply: 24 V DC industrial power input
- Power Consumption: ≤ 15 W (low‑energy operation)
- Isolation: 2500 V RMS galvanic isolation between CPU and I/O systems
- Protection: Overvoltage, overcurrent, and reverse polarity protection
Mechanical & Physical Parameters
- Form Factor: Compact DIN‑rail mountable CPU module
- Dimensions: 145 mm × 90 mm × 125 mm
- Weight: 1.0 kg
- Terminals: Pluggable screw terminals for easy wiring
- Display: Integrated LCD for status monitoring and diagnostics
- Memory Expansion: SD card slot for program backup and data logging
Environmental & Compliance
- Operating Temperature: -25°C to +60°C (with condensation protection)
- Storage Temperature: -40°C to +85°C
- Humidity: 5%–95% RH (non‑condensing)
- Vibration Resistance: 5g @ 10–150 Hz (complies with IEC 60068‑2‑6)
- Shock Resistance: Complies with IEC 60068‑2‑27 standards
- Protection Class: IP20 (for enclosed control cabinet installation)
- Certifications: CE, IEC 61131‑2, ABB industrial quality standards
System Compatibility
- Compatible Systems: ABB AC900, AC31, AC500 PLC series
- Programming Software: ABB Control Builder, AC1131 programming environment
- Hot‑Swappable: Supports online replacement without system shutdown
- Redundancy Support: Enables high‑availability configurations for critical applications
Key Features
- High‑Speed Processing: 64‑bit multi‑core RISC processor delivers exceptional computational performance
- Extensive I/O Capacity: Manages thousands of digital and analog I/O points for large‑scale systems
- Multi‑Protocol Communication: Supports Ethernet, serial, and fieldbus protocols for flexible integration
- Integrated Diagnostics: Real‑time system monitoring, fault detection, and status reporting via LCD display
- Non‑Volatile Memory: Preserves program and data during power outages
- SD Card Support: Facilitates easy program backup, restoration, and data logging
- Robust Industrial Design: Withstands extreme temperatures, vibration, and electrical interference
- Redundancy Capability: Ensures uninterrupted operation in mission‑critical applications
- Easy Configuration: Intuitive software setup and DIP switch addressing for quick deployment
- Low Power Consumption: Minimizes heat generation and energy costs in control systems
Application Scenarios
- Process Control Systems: Manages complex processes in chemical, pharmaceutical, and oil & gas refineries
- Manufacturing Automation: Controls assembly lines, packaging machinery, and material handling systems
- Power Generation & Distribution: Monitors and controls turbines, generators, and substation equipment
- Metallurgical Industry: Regulates steel production, rolling mills, and metal processing operations
- Cement & Building Materials: Controls kilns, mixers, and batching systems in cement plants
- Water & Wastewater Treatment: Manages pump stations, filtration systems, and water quality monitoring
- Mining & Heavy Equipment: Controls crushers, conveyors, and mineral processing machinery
- Food & Beverage Production: Regulates temperature, pressure, and flow in food processing lines
- Marine & Offshore: Integrates with ship automation and offshore platform control systems
- System Retrofit & Upgrade: Replaces legacy CPU modules in existing ABB PLC systems
