Product Short Description
- Input Voltage: 24 V DC
- Output Voltage: 24 V DC
- Operating Temperature Range: -20°C to +70°C
- Storage Temperature Range: -40°C to +85°C
- Dimensions: 70 mm × 120 mm × 45 mm
- Weight: Approximately 200 g
- Communication Protocols: Ethernet/IP, Modbus TCP, UDP, HTTP, DHCP, ControlNet, RS-232
- I/O Configuration:
- Inputs: Single-phase/three-phase voltage detection, three-phase current detection (1 A or 5 A nominal), auxiliary ±10 V DC input, DC power input.
- Outputs: Pulse-width modulation (PWM) power stage (15 A rated current), discrete redundancy relay outputs, discrete fault output drivers.
- Certifications: CE, UL, KC, RoHS
Description
Functional Features
- Generator Control and Protection:
- Four excitation control modes: Automatic Voltage Regulation (AVR), Field Current Regulation (FCR), Power Factor (PF), and Reactive Power (VAR).
- Soft-start voltage ramp-up in AVR and FCR modes for smooth operation.
- Over-excitation (OEL) and under-excitation (UEL) limits in AVR, VAR, and PF modes.
- Volt/Hz (欠频补偿) and line drop compensation for adaptive voltage control.
- Synchronization and Load Sharing:
- Automatic tracking between operating modes and redundant CGCM units.
- Seamless transfer to backup CGCM units in redundant systems.
- Generator paralleling with reactive power drop compensation or cross-current differential compensation.
- Real power load sharing and single/dual breaker synchronization.
- Monitoring and Diagnostics:
- Real-time monitoring of voltage, current, frequency, and temperature parameters.
- Intelligent diagnostic functions for fault detection and alarm generation.
- Programmable logic control for custom automation workflows.
- Communication and Integration:
- Three communication ports: redundant ControlNet connectors, RS-232 for dedicated CGCM communication, and RS-232 for factory configuration/testing.
- Compatibility with Logix series programmable controllers for seamless system integration.
Application Scenarios
- Power Generation: Used in power plants, wind turbines, and solar inverters to monitor and control generator output, ensuring grid stability and efficiency.
- Industrial Automation: Manages backup power systems, critical equipment供电, and factory power distribution to prevent downtime and ensure continuous operation.
- Water Treatment: Ensures reliable power supply for pumps and filtration systems in water treatment facilities.
- Building Management: Controls backup generators in large buildings, commercial centers, and medical facilities to maintain power during outages.
- Transportation Infrastructure: Supports traffic signals, tunnel lighting, and railway systems by providing stable power in critical applications.
Key Advantages
- High Reliability: Built with high-quality components and strict manufacturing processes to withstand harsh industrial environments.
- Flexibility: Supports multiple excitation control modes and communication protocols for easy integration into diverse systems.
- Scalability: Modular design allows expansion and customization to meet specific application requirements.
- Efficiency Optimization: Reduces fuel consumption and emissions through precise load sharing and voltage regulation.
- Global Compliance: Meets CE, UL, and RoHS standards, ensuring safety and reliability in international markets.
