Description
Technical specifications
-
Channels: 24 total, each configurable as DI or DO
-
Input range: 24 VDC, thresholds ON ≥ 15 V, OFF ≤ 5 V
-
Output specification: 24 VDC, 0.5 A per channel, short-circuit and overload protected
-
Supply voltage: 20.4 – 28.8 VDC
-
Switching frequency: 50 kHz max per channel
-
Isolation: channel-to-bus 500 VAC
-
Wire types: 1- or 2-wire connection supported
-
Diagnostics: status LED per channel, group diagnostics via backplane
-
Operating temperature: 0 °C to +60 °C
-
Protection class: IP20
-
Dimensions: 62 mm × 76 mm × 75 mm (W × H × D)
-
Weight: 0.115 kg
Key features
-
High-density 24-point I/O in one module reduces panel space
-
Each channel individually programmable as input or output via Control Builder
-
Integrated protection against reverse polarity, short circuit and over-temperature
-
Hot-swap capable within AC500 rack
-
Front-facing spring-cage terminals for fast wiring and maintenance
Typical applications
-
Machine automation: packaging, material handling, assembly lines
-
Process industries: valve position feedback, pump start/stop, status indication
-
Building automation: lighting control, HVAC fan and damper interfaces
-
OEM machinery: modular I/O expansion for AC500-based controllers
