Product Short Description
Product Name: B&R 5ACPCI.ETH3-01 Ethernet PCI Communication Card
Product Series: B&R 5AC Series PCI Bus Expansion Card
Product Brief: Industrial PCI bus Ethernet communication expansion card. It is installed in industrial computer or main control device via PCI slot, provides high-speed Ethernet interface, and realizes data communication and network interconnection for B&R industrial control system.
Description
- Bus Type: Standard PCI bus
- Network Interface: 10/100/1000 Mbps adaptive Ethernet
- Operating Voltage: 5 V DC (PCI bus power supply)
- Operating Temperature: 0 °C ~ +60 °C
- Storage Temperature: -20 °C ~ +70 °C
- Relative Humidity: 10% ~ 90% RH (Non-condensing)
- Network Protocol: Standard TCP/IP, industrial Ethernet protocols
- Expand gigabit Ethernet port for industrial host equipment
- High-speed data transmission between host and automation equipment
- Network link status automatic detection and indication
- Hardware-level network data filtering and acceleration
- Compatible with B&R automation software and network management system
- Power Consumption: ≤ 4.5 W
- Network Transmission Rate: Full gigabit adaptive
- PCI Bus Transmission Speed: Standard PCI bus bandwidth
- Vibration Resistance: 5 Hz ~ 120 Hz, 0.6 g
- MTBF: ≥ 88000 hours
- Main Board: Industrial grade PCI standard PCB
- Gold Finger: High-purity copper with gold plating for bus connection
- Network Chip: Industrial gigabit Ethernet control chip
- Network Port: RJ45 industrial network socket
- Metal Bracket: Galvanized steel fixed bracket
- Standard desktop/industrial PCI full-height card structure
- Metal fixed bracket for chassis installation and shielding
- External RJ45 network port on bracket side
- Onboard full solid-state capacitor design for stability
- Standard positioning notch for PCI slot anti-misinsertion
The card obtains power and bus signals from PCI slot of industrial host. The onboard Ethernet chip processes network data packets, realizes mutual conversion between PCI bus data and Ethernet data. It completes data exchange between host and external network devices to achieve system networking and remote data transmission.
- Three-speed adaptive Ethernet, compatible with all mainstream network devices
- Industrial grade design, stable operation in industrial computer environment
- Standard PCI interface, universal installation for industrial hosts
- Low power consumption, no extra heat load for host
- Perfect compatibility with B&R full set industrial software
Industrial computer control system, factory network, data acquisition system, remote monitoring, intelligent workshop, industrial server
- Power off industrial host before inserting into standard PCI slot
- Fasten metal bracket to chassis with fixing screws
- Use standard industrial Ethernet cable for network connection
- Install in well-ventilated chassis slot, avoid overheating
- Keep away from other high-heat expansion cards
- Strictly power off host before plugging and unplugging the card
- Do not bend the board or damage gold fingers during installation
- Keep RJ45 port clean to prevent dust and foreign matter intrusion
- Update matched driver program according to B&R official requirements
- Avoid using in environment with strong electromagnetic interference
